SmokeyColes

Members
  • Posts

    105
  • Joined

  • Last visited

Everything posted by SmokeyColes

  1. SOLVED Ok I don't know how but in case any one finds the same. It could be one of three things (I tested on original VM): 1. Changed PCIe ACS override from Multi-Function to DownStream, the IOMMU group looks slightly different. See this post for IOMMU differences for eGPUs: 2. Changed eGPU to Razor Core X from Lenova BoostStation. 3. When I removed the GPU from the eGPU enclosure, there was a very small piece of paper at the pins. I've no idea if it was causing a problem or where it came from, but I'm going to write it here- as you never know. So sorry I have no solution. DIRT4 is playing flawlessly and I'm no longer < 15fps or 0 moving the mouse. But yay!! Tbh I'm toying with the idea to swap back to the boost station. But its a hit or miss chance it will pick up the GPU. Sometimes I've found you have more chance of UNRAID picking up the GPU when you swap it between thunderbolt enclosures. That said 3 out of 4 times it would see it on Multi-Function, but it was still problematic. Strange, but you never know this post may help someone.... Cheers Chris
  2. Hi I got it working thank you, well partially - I still cant find DVB-T2.. I have disabled DVB-S and DVB-C for now in the TV adaptors tab, and I am using a docker of Binhex-tvheadend which I found in the UNRAID app store, and downloaded. Its in UNRAID > DOCKERS, As I don't believe the issue is the driver now, I've joined tvheadend to ask for help; post is here: https://tvheadend.org/boards/5/topics/46466 Thank you for enabling this driver. If however I have no luck with the DVB-T2 and TVheadend, can I pass this to a VM to try NextPVR (which seems to have great reviews and regular updates). How would I do this to a Windows VM? I saw it doesn't show in other PCI devices, would I pass it through - I am assuming its IOMMU 27 and I just have to tick the checkbox to make it show as an Other PCI device? Then install the driver in Windows. Please forgive my lack of understanding of what your driver is doing - I am guessing its only for the use of dockers in UNRAID, and if I passed it through to the VM - I'd have to disable the driver. (If I cant get tvheadend working correctly)
  3. Hello When I scan for channels in TVHeadEnd - I do not get any HD channels. Can you help me please? It says DVB-T and not DVB-T2 and I think the UK channels I want are DVB-T2 I am using Binhex-tvheadend, as the other one seems no linger supported I am using a Hauppage WinTV-HVR-5525 https://www.hauppauge.co.uk/site/products/data_hvr5525.html I am using a SV9460 aerial https://www.oneforall.co.uk/tv-aerials/sv-9460-amplified-indoor-tv-aerial#/step-1
  4. Reinstalled a new VM using Q35 and complete clean setup, but this time with no vbios and gpu from the start (no vnc) - had the identical same issue. i440 bios crashes the VM, if I Force Stop - UNRAID crashes. If I switch off GPU first (by the egpu enclosure) - then Force Stop - the VM can be stopped. Part of me is wondering if its the egpu. Any thoughts would be appreciated...
  5. Hello Can you tell me if this is correct, I can't work out which is the AV In? Thank you I am assuming DVB-C uses the same input as DVB-S?
  6. Hi Am I correct in saying there is 2 dockers for PVR. I was wondering what the difference is between tvheadend and binhex-tvheadend. Does anyone use these for kodi?
  7. Hi I've decided to have another stab at a Win11 Pro VM from fresh. I have a 10900K cpu using host passthrough with a i440fx-6.1 bios, with a GTX1660 (no vbios) I am at the install with the loaded windows 10 driver from 208 virtio iso. Under viostor Do I use AMD 64 drivers? The other choice are x86 or ARM64 Thanks
  8. On running dirt4, there is a spinning icon. I noticed that when I move the mouse - it does indeed cause the spinning icon to sort of stop and then pick up again. I think this is a good idea, but truthfully I've no idea what I am doing, I did select the GTX and HD Audio as MSI (tick box and press apply, reboot) but it didn't improve. I am at a complete loss here, I've tried selecting all to MSI, and enabling HD audio and GTX1660 to high. I did try seeing if I could change the VM BIOS from Q35-6.1 to i440fx-6.1, but I get the error: XML error: The PCI controller with index='0' must be model='pci-root' for this machine type, but model='pcie-root' was found instead I'm not sure if that will make a difference. Other things I tried are turning off the other NVIDIA things. It made no difference (maybe made it worse) I have turned back on the TU116 USB and UCSI controller. MSI is enabled on all devices with GTX and HD Audio set at HIGH Interrupt Priority. Thing is I don't know if this is related to egpu thunderbolt or not.. The vbios was from a website as the script to dump the vbios does not work. I'm stumped!
  9. Games are still choppy (like as if its max at 100% and needs to catch up); better but choppy - both halo and drift4. When I use the XBOX controller overlay which shows VRAM, GPU, CPU - they are barely going over 50%. Graphics are on low or medium, since doing the xml changes - I have not done a clean install of the driver? Have you any thoughts? Thanks Chris <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' id='59'> <name>Win11Pro-KodiPlex</name> <uuid>1339d88c-f600-3c3d-6562-f78a4f7d2d78</uuid> <metadata> <vmtemplate xmlns="unraid" name="Windows 11" icon="windows11.png" os="windowstpm"/> </metadata> <memory unit='KiB'>16777216</memory> <currentMemory unit='KiB'>16777216</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>12</vcpu> <cputune> <vcpupin vcpu='0' cpuset='4'/> <vcpupin vcpu='1' cpuset='14'/> <vcpupin vcpu='2' cpuset='5'/> <vcpupin vcpu='3' cpuset='15'/> <vcpupin vcpu='4' cpuset='6'/> <vcpupin vcpu='5' cpuset='16'/> <vcpupin vcpu='6' cpuset='7'/> <vcpupin vcpu='7' cpuset='17'/> <vcpupin vcpu='8' cpuset='8'/> <vcpupin vcpu='9' cpuset='18'/> <vcpupin vcpu='10' cpuset='9'/> <vcpupin vcpu='11' cpuset='19'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-q35-6.1'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi-tpm.fd</loader> <nvram>/etc/libvirt/qemu/nvram/1339d88c-f600-3c3d-6562-f78a4f7d2d78_VARS-pure-efi-tpm.fd</nvram> </os> <features> <acpi/> <apic/> <hyperv> <relaxed state='on'/> <vapic state='on'/> <spinlocks state='on' retries='8191'/> <vpindex state='on'/> <runtime state='on'/> <synic state='on'/> <stimer state='on'/> <reset state='on'/> <vendor_id state='on' value='pickyourown'/> </hyperv> </features> <cpu mode='host-passthrough' check='none' migratable='on'> <topology sockets='1' dies='1' cores='6' threads='2'/> <cache mode='passthrough'/> </cpu> <clock offset='localtime'> <timer name='hypervclock' present='yes'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='writeback'/> <source file='/mnt/user/domains/Windows 11/vdisk1.img' index='4'/> <backingStore/> <target dev='hdc' bus='virtio'/> <boot order='1'/> <alias name='virtio-disk2'/> <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </disk> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='writeback'/> <source file='/mnt/user/domains/Win11Pro-KodiPlex/vdisk2.img' index='3'/> <backingStore/> <target dev='hdd' bus='virtio'/> <alias name='virtio-disk3'/> <address type='pci' domain='0x0000' bus='0x05' slot='0x00' function='0x0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/Win11_English_x64v1.iso' index='2'/> <backingStore/> <target dev='hda' bus='sata'/> <readonly/> <boot order='2'/> <alias name='sata0-0-0'/> <address type='drive' controller='0' bus='0' target='0' unit='0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/virtio-win-0.1.208-1.iso' index='1'/> <backingStore/> <target dev='hdb' bus='sata'/> <readonly/> <alias name='sata0-0-1'/> <address type='drive' controller='0' bus='0' target='0' unit='1'/> </disk> <controller type='pci' index='0' model='pcie-root'> <alias name='pcie.0'/> </controller> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x10'/> <alias name='pci.1'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x11'/> <alias name='pci.2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0x12'/> <alias name='pci.3'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x2'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0x13'/> <alias name='pci.4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x3'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0x14'/> <alias name='pci.5'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x4'/> </controller> <controller type='pci' index='6' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='6' port='0x8'/> <alias name='pci.6'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='7' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='7' port='0x9'/> <alias name='pci.7'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='8' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='8' port='0xa'/> <alias name='pci.8'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/> </controller> <controller type='pci' index='9' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='9' port='0xb'/> <alias name='pci.9'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x3'/> </controller> <controller type='pci' index='10' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='10' port='0xc'/> <alias name='pci.10'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x4'/> </controller> <controller type='pci' index='11' model='pcie-to-pci-bridge'> <model name='pcie-pci-bridge'/> <alias name='pci.11'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </controller> <controller type='sata' index='0'> <alias name='ide'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <controller type='usb' index='0' model='nec-xhci' ports='15'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:a9:3e:55'/> <source bridge='br0'/> <target dev='vnet52'/> <model type='virtio-net'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/1'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/1'> <source path='/dev/pts/1'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/var/lib/libvirt/qemu/channel/target/domain-59-Win11Pro-KodiPlex/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='disconnected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <alias name='input0'/> <address type='usb' bus='0' port='1'/> </input> <input type='mouse' bus='ps2'> <alias name='input1'/> </input> <input type='keyboard' bus='ps2'> <alias name='input2'/> </input> <tpm model='tpm-tis'> <backend type='emulator' version='2.0' persistent_state='yes'/> <alias name='tpm0'/> </tpm> <audio id='1' type='none'/> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x0'/> </source> <alias name='hostdev0'/> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x0' multifunction='on'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x1'/> </source> <alias name='hostdev1'/> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x1'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x2'/> </source> <alias name='hostdev2'/> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x2'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x3'/> </source> <alias name='hostdev3'/> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x3'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x045e'/> <product id='0x02fe'/> <address bus='1' device='31'/> </source> <alias name='hostdev4'/> <address type='usb' bus='0' port='2'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x046d'/> <product id='0xc52b'/> <address bus='1' device='46'/> </source> <alias name='hostdev5'/> <address type='usb' bus='0' port='3'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x1c4f'/> <product id='0x0026'/> <address bus='1' device='13'/> </source> <alias name='hostdev6'/> <address type='usb' bus='0' port='4'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x413c'/> <product id='0x3012'/> <address bus='1' device='12'/> </source> <alias name='hostdev7'/> <address type='usb' bus='0' port='5'/> </hostdev> <memballoon model='none'/> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> </domain>
  10. Hi there good morning - thank you. I will make the changes suggested shortly to the XML - thankyou. Answers to the other questions are below (I believe they are setup correctly although not 100% sure) Here is the details: VM Details: Cache 2x NVME M2 (system_cache): Cache Win11 (56GB > 400GB): Cache Game Drive (213GB > 1TB): Domains Share Settings: CPU Pinning: Pair 1: cpu 0 / cpu 10 Pair 2: cpu 1 / cpu 11 Pair 3: cpu 2 / cpu 12 Pair 4: cpu 3 / cpu 13 Pair 5: cpu 4 / cpu 14 Pair 6: cpu 5 / cpu 15 Pair 7: cpu 6 / cpu 16 Pair 8: cpu 7 / cpu 17 Pair 9: cpu 8 / cpu 18 Pair 10: cpu 9 / cpu 19 I will be running 2 VMs at one time. HS Server (Ubuntu) - needs little resource KodiPlex (Windows 11) Would you suggest: UNRAID cpu 0/10 + cpu 1 /11 HS Server cpu 2/12 + cpu 3/13 KodiPlex cpu 4/14 + 5/15 cpu 6/16 + 7/16 cpu 8/18 + 9/19 Is that OK? Whilst I'm testing KodiPlex (with above setup) - I don't have any other VMs running (e.g. no ubuntu) - so UNRAID should be using the first 4 cores (if my understanding is correct).
  11. Hi I have a new VM setup. I would like a pro to take a look please. Its is struggling to Play Dirt 4 on Steam - and I'm a bit baffled because I thought this would be more than capable. It's choppy and sluggish to respond. I am just wondering if I have messed something up - very obvious to someone? <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' id='58'> <name>Win11Pro-KodiPlex</name> <uuid>1339d88c-f600-3c3d-6562-f78a4f7d2d78</uuid> <metadata> <vmtemplate xmlns="unraid" name="Windows 11" icon="windows11.png" os="windowstpm"/> </metadata> <memory unit='KiB'>16777216</memory> <currentMemory unit='KiB'>16777216</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>12</vcpu> <cputune> <vcpupin vcpu='0' cpuset='2'/> <vcpupin vcpu='1' cpuset='12'/> <vcpupin vcpu='2' cpuset='3'/> <vcpupin vcpu='3' cpuset='13'/> <vcpupin vcpu='4' cpuset='4'/> <vcpupin vcpu='5' cpuset='14'/> <vcpupin vcpu='6' cpuset='5'/> <vcpupin vcpu='7' cpuset='15'/> <vcpupin vcpu='8' cpuset='6'/> <vcpupin vcpu='9' cpuset='16'/> <vcpupin vcpu='10' cpuset='7'/> <vcpupin vcpu='11' cpuset='17'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-q35-6.1'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi-tpm.fd</loader> <nvram>/etc/libvirt/qemu/nvram/1339d88c-f600-3c3d-6562-f78a4f7d2d78_VARS-pure-efi-tpm.fd</nvram> </os> <features> <acpi/> <apic/> <hyperv> <relaxed state='on'/> <vapic state='on'/> <spinlocks state='on' retries='8191'/> <vendor_id state='on' value='none'/> </hyperv> </features> <cpu mode='host-passthrough' check='none' migratable='on'> <topology sockets='1' dies='1' cores='6' threads='2'/> <cache mode='passthrough'/> </cpu> <clock offset='localtime'> <timer name='hypervclock' present='yes'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='writeback'/> <source file='/mnt/user/domains/Windows 11/vdisk1.img' index='4'/> <backingStore/> <target dev='hdc' bus='virtio'/> <boot order='1'/> <alias name='virtio-disk2'/> <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </disk> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='writeback'/> <source file='/mnt/user/domains/Win11Pro-KodiPlex/vdisk2.img' index='3'/> <backingStore/> <target dev='hdd' bus='virtio'/> <alias name='virtio-disk3'/> <address type='pci' domain='0x0000' bus='0x05' slot='0x00' function='0x0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/Win11_English_x64v1.iso' index='2'/> <backingStore/> <target dev='hda' bus='sata'/> <readonly/> <boot order='2'/> <alias name='sata0-0-0'/> <address type='drive' controller='0' bus='0' target='0' unit='0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/virtio-win-0.1.208-1.iso' index='1'/> <backingStore/> <target dev='hdb' bus='sata'/> <readonly/> <alias name='sata0-0-1'/> <address type='drive' controller='0' bus='0' target='0' unit='1'/> </disk> <controller type='usb' index='0' model='nec-xhci' ports='15'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/> </controller> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x10'/> <alias name='pci.1'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x11'/> <alias name='pci.2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0x12'/> <alias name='pci.3'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x2'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0x13'/> <alias name='pci.4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x3'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0x14'/> <alias name='pci.5'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x4'/> </controller> <controller type='pci' index='6' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='6' port='0x8'/> <alias name='pci.6'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='7' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='7' port='0x9'/> <alias name='pci.7'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='8' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='8' port='0xa'/> <alias name='pci.8'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/> </controller> <controller type='pci' index='9' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='9' port='0xb'/> <alias name='pci.9'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x3'/> </controller> <controller type='pci' index='10' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='10' port='0xc'/> <alias name='pci.10'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x4'/> </controller> <controller type='pci' index='11' model='pcie-to-pci-bridge'> <model name='pcie-pci-bridge'/> <alias name='pci.11'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </controller> <controller type='sata' index='0'> <alias name='ide'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <controller type='pci' index='0' model='pcie-root'> <alias name='pcie.0'/> </controller> <interface type='bridge'> <mac address='52:54:00:a9:3e:55'/> <source bridge='br0'/> <target dev='vnet51'/> <model type='virtio-net'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/1'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/1'> <source path='/dev/pts/1'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/var/lib/libvirt/qemu/channel/target/domain-58-Win11Pro-KodiPlex/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='connected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <alias name='input0'/> <address type='usb' bus='0' port='1'/> </input> <input type='mouse' bus='ps2'> <alias name='input1'/> </input> <input type='keyboard' bus='ps2'> <alias name='input2'/> </input> <tpm model='tpm-tis'> <backend type='emulator' version='2.0' persistent_state='yes'/> <alias name='tpm0'/> </tpm> <audio id='1' type='none'/> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x0'/> </source> <alias name='hostdev0'/> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x1'/> </source> <alias name='hostdev1'/> <address type='pci' domain='0x0000' bus='0x07' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x2'/> </source> <alias name='hostdev2'/> <address type='pci' domain='0x0000' bus='0x08' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x3'/> </source> <alias name='hostdev3'/> <address type='pci' domain='0x0000' bus='0x09' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x045e'/> <product id='0x02fe'/> <address bus='1' device='31'/> </source> <alias name='hostdev4'/> <address type='usb' bus='0' port='2'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x046d'/> <product id='0xc52b'/> <address bus='1' device='46'/> </source> <alias name='hostdev5'/> <address type='usb' bus='0' port='3'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x1c4f'/> <product id='0x0026'/> <address bus='1' device='13'/> </source> <alias name='hostdev6'/> <address type='usb' bus='0' port='4'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x413c'/> <product id='0x3012'/> <address bus='1' device='12'/> </source> <alias name='hostdev7'/> <address type='usb' bus='0' port='5'/> </hostdev> <memballoon model='none'/> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> </domain>
  12. Hi I am trying to map a network drive z:\\ I type in \\unraidnas\ and I can see all my sub folder shares; e.g. movies, tv shows, documents.. But it doesn't allow me to use the root as a network drive, so I only have one z drive which displays all the shares. e.g. "\\unraidnas\" instead of "\\unraidnas\movies\" Is there an easy way to do this with the unraid settings? Or do I have to setup folder shares/drives for each subfolder. Thanks Chris
  13. CPU is a 10900K Yes your right; I tried a 2nd attempt and gave it a cpu 0/10 and 1/11 My ubuntu VM I have given most of the rest, which I will change as I migrate plex and kodi I'm looking to transfer from ubuntu to windows as I am having problems with kodi, steam - pulseaudio/alsa Its OK to change the CPU in the future right? Give it more cores?
  14. Hello I know SpaceInvadeOne and Linus have videos how to install Windows 11 using the insider iso's. Is it possible to install Windows 11 with everything emulated using a normal iso downloaded straight from the Microsoft website (latest). I have tried and I get the error "this pc can't run windows 11" - doesn't really tell me anything more. I am using UNRAID 6.10.0-rc2 Is it possible, do you know what settings I have wrong? cpu mode host passthrough memory 4096, 4096 cpu 0/10 i440fx-6.1 OVMF TPM Hyper-V Yes USB 3 qemu XHCI graphics VNC Low spec I know, but I plan to change later. ** Lowish technical knowledge with KVM, I've set up a couple **
  15. @ghost82 I am glad its clear to one of us! When I selected the Graphics Card dropdown at the time I had just: VNC Intel UHD Graphics 630 At the time - I was booting UNRAID without a GPU so I think UNRAID was using my 630 graphics even in non-GUI mode (text only). I may have incorrectly expected the unraid command line text on the monitor to switch over to the VM. I think this was an incorrect understanding of mine and causing the attempted double use. Currently - I don't think this iGPU approach is a viable option for me as my motherboard only allows a single GPU to be installed in a certain slot (and this means I loose one of my 3 HBA's which are in pciex8 slots). I did try a GT730 - GT730-4H-SL-2GD5 (on a pcie x1 slot) in the hope of having UNRAID output on that, and a VM on the motherboard hdmi iGPU (UHD630) but the thing refused to boot using the GPU in a different slot (opposed to the certain slot described in the manual) My current options (I think) are: 1 - Mess about with boots until it sees a GPU in a thunderbolt eGPU, and leave unraid useing the iGPU & motherboard hdmi (regardless of GUI or command mode) 2 - Remove a HBA from Slot1, and install a GPU, boot unraid in iGPU and use VM GPU 3 - Remove a HBA from Slot1 and install a GPU, boot unraid in GPU and use VM iGPU It is a real shame as the system was specified for the eGPU design, and using 3x HBA controllers in pciex8, and 2 spare pciex1 slots. Feel free to correct my understanding of the iGPU? Below is the XML Thanks Chris <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' id='26'> <name>KodiPlex-Server</name> <uuid>243a16ff-92c1-37ae-f8e6-7b5d3367ef38</uuid> <metadata> <vmtemplate xmlns="unraid" name="Ubuntu" icon="ubuntu.png" os="ubuntu"/> </metadata> <memory unit='KiB'>15728640</memory> <currentMemory unit='KiB'>15728640</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>8</vcpu> <cputune> <vcpupin vcpu='0' cpuset='2'/> <vcpupin vcpu='1' cpuset='12'/> <vcpupin vcpu='2' cpuset='3'/> <vcpupin vcpu='3' cpuset='13'/> <vcpupin vcpu='4' cpuset='4'/> <vcpupin vcpu='5' cpuset='14'/> <vcpupin vcpu='6' cpuset='5'/> <vcpupin vcpu='7' cpuset='15'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-q35-5.1'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/243a16ff-92c1-37ae-f8e6-7b5d3367ef38_VARS-pure-efi.fd</nvram> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none' migratable='on'> <topology sockets='1' dies='1' cores='4' threads='2'/> <cache mode='passthrough'/> </cpu> <clock offset='utc'> <timer name='rtc' tickpolicy='catchup'/> <timer name='pit' tickpolicy='delay'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/system_cache/domains/Kodi Plex Server/vdisk1.img' index='2'/> <backingStore/> <target dev='hdc' bus='virtio'/> <boot order='1'/> <alias name='virtio-disk2'/> <address type='pci' domain='0x0000' bus='0x05' slot='0x00' function='0x0'/> </disk> <disk type='file' device='cdrom'> <driver name='qemu' type='raw'/> <source file='/mnt/user/isos/ubuntu-21.10-desktop-amd64.iso' index='1'/> <backingStore/> <target dev='hda' bus='sata'/> <readonly/> <boot order='2'/> <alias name='sata0-0-0'/> <address type='drive' controller='0' bus='0' target='0' unit='0'/> </disk> <controller type='pci' index='0' model='pcie-root'> <alias name='pcie.0'/> </controller> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x10'/> <alias name='pci.1'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x11'/> <alias name='pci.2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0x12'/> <alias name='pci.3'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x2'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0x13'/> <alias name='pci.4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x3'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0x14'/> <alias name='pci.5'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x4'/> </controller> <controller type='pci' index='6' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='6' port='0x15'/> <alias name='pci.6'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x5'/> </controller> <controller type='pci' index='7' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='7' port='0x16'/> <alias name='pci.7'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x6'/> </controller> <controller type='pci' index='8' model='pcie-to-pci-bridge'> <model name='pcie-pci-bridge'/> <alias name='pci.8'/> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </controller> <controller type='pci' index='9' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='9' port='0x8'/> <alias name='pci.9'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='10' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='10' port='0x9'/> <alias name='pci.10'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='11' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='11' port='0xa'/> <alias name='pci.11'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/> </controller> <controller type='pci' index='12' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='12' port='0xb'/> <alias name='pci.12'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x3'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </controller> <controller type='sata' index='0'> <alias name='ide'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <controller type='usb' index='0' model='qemu-xhci' ports='15'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0'/> </controller> <filesystem type='mount' accessmode='passthrough'> <source dir='/mnt/user/'/> <target dir='UnraidShares'/> <alias name='fs0'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </filesystem> <interface type='bridge'> <mac address='52:54:00:d7:b6:2b'/> <source bridge='br0'/> <target dev='vnet19'/> <model type='virtio-net'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/1'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/1'> <source path='/dev/pts/1'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/var/lib/libvirt/qemu/channel/target/domain-26-KodiPlex-Server/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='disconnected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <alias name='input0'/> <address type='usb' bus='0' port='1'/> </input> <input type='mouse' bus='ps2'> <alias name='input1'/> </input> <input type='keyboard' bus='ps2'> <alias name='input2'/> </input> <audio id='1' type='none'/> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x0'/> </source> <alias name='hostdev0'/> <rom file='/mnt/user/isos/vbios/GTX1660.rom'/> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x1'/> </source> <alias name='hostdev1'/> <address type='pci' domain='0x0000' bus='0x07' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x2'/> </source> <alias name='hostdev2'/> <address type='pci' domain='0x0000' bus='0x09' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x45' slot='0x00' function='0x3'/> </source> <alias name='hostdev3'/> <address type='pci' domain='0x0000' bus='0x0a' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x045e'/> <product id='0x02fe'/> <address bus='1' device='31'/> </source> <alias name='hostdev4'/> <address type='usb' bus='0' port='2'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x1c4f'/> <product id='0x0026'/> <address bus='1' device='13'/> </source> <alias name='hostdev6'/> <address type='usb' bus='0' port='4'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source startupPolicy='optional'> <vendor id='0x046d'/> <product id='0xc52b'/> <address bus='1' device='44'/> </source> <alias name='hostdev7'/> <address type='usb' bus='0' port='3'/> </hostdev> <memballoon model='none'/> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> </domain>
  16. Hi when I try to change a USB device whilst the VM is running, I get the following error: error: Invalid value for attribute 'id' in element 'product': '0x00db#remove'. Expected integer value , error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x00db#remove'. Expected integer value Device attached successfully error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x0200#remove'. Expected integer value , error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x00db#remove'. Expected integer value Device attached successfully error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x0200#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x8153#remove'. Expected integer value , error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x00db#remove'. Expected integer value Device attached successfully error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x0200#remove'. Expected integer value error: Faildiagnostics-20211218-1424.ziped to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x8153#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0xfdc0#remove'. Expected integer value , error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x00db#remove'. Expected integer value Device attached successfully error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x0200#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x8153#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0xfdc0#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x01a2#remove'. Expected integer value , error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x00db#remove'. Expected integer value Device attached successfully error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x0200#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x8153#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0xfdc0#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x01a2#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x3012#remove'. Expected integer value , error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x00db#remove'. Expected integer value Device attached successfully error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x0200#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0x8153#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': '0xfdc0#remove'. Expected integer value error: Failed to attach device from /tmp/hotattach.tmp error: XML error: Invalid value for attribute 'id' in element 'product': It still does the change if i press the back button and the VM is fine, works as if you have just plugged in a USB. I don't actually see the full error as the pop up fills the screen. Its really frustrating - I don't even see the OK button or an X. Diagnostics attached Thanks diagnostics-20211218-1424.zip
  17. @limetech Hi can you provide any advice? the thunderbolt eGPU shows (TitanRidge) but not the GPU echo 1 > /sys/bus/pci/rescan will then show the GPU every time... however by this point where I am typing the command; the system has booted and the VFIOs are not binded (green dots in the device scanner) - is there any way I can force this pci rescan before vfio bindings are established, so it sees the GPU? Thanks
  18. Ok so this is what I did and I resolved it myself. It requires lots of testing reboots and switching between KVM VNC and GPU. This is no means a science but if it helps others (rather than getting no response - please use, and like!!) Though before you do, use a backup VM plugin / script so you have a backup to fallback on (even if the backups in a bad state). The idea is I literally tried everything - Display Manager (your linux login), drivers (GPU), and a attack on GRUB. I could create a new VM so I was fortunate to see this working (so I knew it was software on the VM) although UNRAID it is a real shame, there is no force a boot from a Live CD (post install) and you sure as hell wont get support! For me GPU vbios did nothing so I didn't use it, and the official nvidia drivers don't play well at all on my system. It took me days of effort... lots of learning! So here are some useful commands, I really recommend getting SSH installed anyway you can. That is my number 1 tip, 2nd - backup VM vdisk. Things are so much less bleak when you know its talking back to you and not just stalled on the black screen. I've tried to make the process sequential however truthfully you may need to jump around the steps. Basics: ======= sudo apt update sudo apt install openssh-server [allows you to SSH into a black screen for terminal on another PC] sudo apt-get install --reinstall ubuntu-desktop gnome-shell ubuntu-gnome-desktop unity [reinstalls all post display manager stuff] sudo reboot Display Manager: ================ cat /etc/X11/default-display-manager /usr/sbin/lightdm sudo apt purge gdm3 lightdm sudo apt-get install lightdm [OR] sudo apt install gdm3 [preferred] systemctl disable lightdm systemctl enable gdm sudo dpkg-reconfigure lightdm [OR] sudo dpkg-reconfigure gdm3 [select gdm3] sudo nano /etc/gdm3/custom.conf [change #WaylandEnable=false, remove comment if needed] sudo service gdm start sudo reboot Drivers: ======== sudo apt-get remove --purge '^nvidia-.*' sudo apt-get remove --purge xserver-xorg* sudo rm /etc/X11/xorg.conf [this was posted on every site, file didn't even exist for me but I reckon this is a regular problem] sudo ubuntu-drivers devices [shows GPU drivers] sudo apt-get install --reinstall nvidia-common sudo apt-get install (driver from above) e.g. sudo apt-get xserver-xorg-video-nouveau sudo apt autoremove sudo apt install nvidia-prime sudo prime-select nvidia nvidia-settings sudo reboot GRUB ==== sudo nano /etc/default/grub to change GRUB_CMDLINE_LINUX_DEFAULT="quiet splash" to be GRUB_CMDLINE_LINUX_DEFAULT="quiet splash nouveau.modeset=0" sudo update-grub sudo reboot Boot Repair App (I didn't try this but found it) ================ sudo apt-add-repository ppa:yannubuntu/boot-repair sudo apt-get updatesudo sudo apt-get install -y boot-repair boot-repair
  19. BUMP does anyone know how i can force the recovery process in ubuntu within a VM?
  20. Hi I have a Ubuntu VM, with VFIO GTX1660 Ventus OC 6GB. I am passing through the Nvidia video, sound, usb, and one more (they are bound together). My Overide is multifunction. The binding has the green dots. I have tried: SpaceInvader vbios sccript - script fails, so no option No bios Tech bios download with hex editor When I boot Ubuntu if I have purged all NVIDIA drivers through VNC and then run ubuntu in GPU passthrough - The Tiana logo loads with a ubuntu logo - then i get a solid black screen (no flashing cursor) I cant input or do anything except force stop. If I purge NVIDIA drivers then install sudo apt-get install nvidia-drivers-470 I then get a black screen with a flashing underscore character. Whether I use the vbios seems to make no difference. I have searched the unraid forums and tried many things, but I am at a loss now. One option I want to try is booting in a ubuntu safe mode, the problem is i have no idea how to do this within a VM. But if someone knows the solution, I would be so grateful. Up to now everything has failed with my VM attempts and I'm sort of at the point of quitting with unraid all together, I've a good setup and is gutting to see every effort fail so badly with no help or support.
  21. Does this no longer work. a also have the binding vfio and get a Tom input output error?
  22. Hello Please can I have some help. I'm pretty sure I explored this before and I couldn't do what I needed. I have a AsRock Creator W480 with i9-9000k CPU I have a monitor attached to the HDMI output on the motherboard I have no GPU installed I have booted unraid to OS with no GUI In my VM for the Graphics Card, I select Intel UHD Graphics 630. I get the following error: XML error: Attempted double use of PCI Address 0000:00:02.0 I do have Intel igpu top installed - but I dont use it for dockers. I think up to now it was used for just the GUI. Do I need to uninstall. I also have Intel GVT-g installed. I can set i915-GVTg-V5_4 (i915-GVTg_V5_4: VMEM: <128MB, 512MB>, up to 1920x1200) to my KodiPlex-Server When I go back into the VM edit and select Intel UHD Graphics 630 I get the same error. Does anyone have experience and could tell me how to make the UHD igpu hdmi out be used for my VM? Do I need to delete Intel GPU Top?
  23. Actually I think this whole post may be nonsense; I do not get green circles (only occasionally) and get bind errors. I think this is related to the fact I have to do pci rescan's. Does anyone know how to force it reload vfio (except at boot) ?
  24. The USB controllers don't show at all now - they looked exactly like this (taken from someone elses post) asmedia usb and anything plugged into them no longer work.
