have you tried setting up syslog server or writing a copy to usb? it'll preserve everything up to the moment of lockup

see if you can capture what the call trace is for. that could help.

I would wait and see if you can get stability first. I don’t think it’s an issue but it’s one other thing that could be eliminated in a step by step process. If you are stable without it, you can always add/replace cache with it after.

I see lots of network errors in the last syslog you uploaded, along with some BRRFS warnings. But one thing at a time. Sometimes HP Proliant onboard network controllers are stupid. So let's try this: Make a copy of your network.cfg file for safe keeping. Then delete the one you have off the usb drive. This will reset network configuration. Also disable the openvpn plugin. Boot normally and see if the problem fixes itself. If so, then re-enamble openvpn and reboot. If it crashes, then you have a configuration issue with openvpn OR the onboard controllers are being finicky with correct settings and there is nothing more to be done except to try the latest beta with newer linux kernel or go without openvpn. If it crashes regardless of the above, then if you're only using one of your ports, disable the others in Unraid networking settings. If it crashes, then go into the bios and manually disable the ports you aren't using, delete the network.cfg file again, and reboot.

EDAC MC0: 1 CE error on CPU#0Channel#1_DIMM#0 EDAC MC0: 1 CE error on CPU#0Channel#2_DIMM#0 looking it up on the interwebs shows ram issue. So, probable ram error on Dim 0. Reseat the dim and see if it goes away. If not, then swap it to a different slot with another stick and see if the error follows it to the new dim number. If so, bad ram stick. If the error stays on dim 0, then there may be a problem with the slot or cpu. But most likely ram stick issue. that's my guess/troubleshooting.

I think I win... or lose... overnight "idle" low is about 217 watts. But it's never really at idle.That includes: 2 8 core processors (32 threads) 128 GB ram 5 disk main array in various states of spun up and down 7 disk backup pool spun down 2 SSD cache up 4 SSD pool up 1 vm running with 2 rx580's and some various dockers contributing to a few watts here and there.

status is still pending. it looked like it was working, but was not. it's a little tricky to explain but compiling showed no errors and passthrough was intermittent for some undetermined reason. once 6.9 goes into RC phase we will then attempt to try again. this is because it may take a combination of 6.9 but using a more recent linux kernel. or not. we'll know more once we get there. if anyone wants to playground, then I recommend downloading the kernel compiling plugin as a start. in some ways it has expedited the process of working on it.

But if it was later, how could we really know?

brothers and sisters, I'm here to testify! thanks to this thread and specifically to @ghost82 I am a a redeemed clover convert and a believer in opencore. not only is the vm booting faster, but I'm benchmarking 10% higher than the same os image on clover. And free performance is worth a lot. THANKS!

xml (had to copy from the running vm) <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' id='34' xmlns:qemu='http://libvirt.org/schemas/domain/qemu/1.0'> <name>Desktop</name> <uuid>9e8e043c-3cfd-8a45-aeac-d80f5cbd234f</uuid> <metadata> <vmtemplate xmlns="unraid" name="MacOS" icon="/mnt/user/domains/MacinaboxCatalina/icon/catalina.png" os="Catalina"/> </metadata> <memory unit='KiB'>101187584</memory> <currentMemory unit='KiB'>101187584</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>24</vcpu> <cputune> <vcpupin vcpu='0' cpuset='4'/> <vcpupin vcpu='1' cpuset='20'/> <vcpupin vcpu='2' cpuset='5'/> <vcpupin vcpu='3' cpuset='21'/> <vcpupin vcpu='4' cpuset='6'/> <vcpupin vcpu='5' cpuset='22'/> <vcpupin vcpu='6' cpuset='7'/> <vcpupin vcpu='7' cpuset='23'/> <vcpupin vcpu='8' cpuset='8'/> <vcpupin vcpu='9' cpuset='24'/> <vcpupin vcpu='10' cpuset='9'/> <vcpupin vcpu='11' cpuset='25'/> <vcpupin vcpu='12' cpuset='10'/> <vcpupin vcpu='13' cpuset='26'/> <vcpupin vcpu='14' cpuset='11'/> <vcpupin vcpu='15' cpuset='27'/> <vcpupin vcpu='16' cpuset='12'/> <vcpupin vcpu='17' cpuset='28'/> <vcpupin vcpu='18' cpuset='13'/> <vcpupin vcpu='19' cpuset='29'/> <vcpupin vcpu='20' cpuset='14'/> <vcpupin vcpu='21' cpuset='30'/> <vcpupin vcpu='22' cpuset='15'/> <vcpupin vcpu='23' cpuset='31'/> </cputune> <resource> <partition>/machine</partition> </resource> <os> <type arch='x86_64' machine='pc-q35-3.1'>hvm</type> <loader readonly='yes' type='pflash'>/mnt/scratch/vm/Desktop/ovmf/OVMF_CODE.fd</loader> <nvram>/mnt/scratch/vm/Desktop/ovmf/OVMF_VARS.fd</nvram> </os> <features> <acpi/> <apic/> <ioapic driver='qemu'/> </features> <cpu mode='host-passthrough' check='none'> <cache mode='passthrough'/> </cpu> <clock offset='utc'> <timer name='rtc' tickpolicy='catchup'/> <timer name='pit' tickpolicy='delay'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='none' io='native' discard='unmap'/> <source file='/mnt/user/vm/Desktop/Clover.qcow2' index='4'/> <backingStore/> <target dev='hdc' bus='sata'/> <boot order='1'/> <alias name='sata0-0-2'/> <address type='drive' controller='0' bus='0' target='0' unit='2'/> </disk> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='none' io='native' discard='unmap'/> <source file='/mnt/scratch/vm/Desktop/macos_disk.qcow2' index='3'/> <backingStore/> <target dev='hdd' bus='sata'/> <alias name='sata0-0-3'/> <address type='drive' controller='0' bus='0' target='0' unit='3'/> </disk> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='none' io='native' discard='unmap'/> <source file='/mnt/scratch/vm/Scratch and Apps Disk/Scratch.qcow2' index='2'/> <backingStore/> <target dev='hde' bus='sata'/> <alias name='sata0-0-4'/> <address type='drive' controller='0' bus='0' target='0' unit='4'/> </disk> <disk type='file' device='disk'> <driver name='qemu' type='qcow2' cache='writeback'/> <source file='/mnt/disks/MacBackup/Backup/vdisk1.qcow2' index='1'/> <backingStore/> <target dev='hdf' bus='sata'/> <alias name='sata0-0-5'/> <address type='drive' controller='0' bus='0' target='0' unit='5'/> </disk> <controller type='usb' index='0' model='ich9-ehci1'> <alias name='usb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x7'/> </controller> <controller type='usb' index='0' model='ich9-uhci1'> <alias name='usb'/> <master startport='0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci2'> <alias name='usb'/> <master startport='2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x1'/> </controller> <controller type='usb' index='0' model='ich9-uhci3'> <alias name='usb'/> <master startport='4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x2'/> </controller> <controller type='sata' index='0'> <alias name='ide'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <controller type='pci' index='0' model='pcie-root'> <alias name='pcie.0'/> </controller> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x8'/> <alias name='pci.1'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x9'/> <alias name='pci.2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0xa'/> <alias name='pci.3'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0xb'/> <alias name='pci.4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x3'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0xc'/> <alias name='pci.5'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x4'/> </controller> <controller type='pci' index='6' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='6' port='0xd'/> <alias name='pci.6'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x5'/> </controller> <controller type='pci' index='7' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='7' port='0xe'/> <alias name='pci.7'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x6'/> </controller> <controller type='pci' index='8' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='8' port='0xf'/> <alias name='pci.8'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x7'/> </controller> <controller type='pci' index='9' model='pcie-to-pci-bridge'> <model name='pcie-pci-bridge'/> <alias name='pci.9'/> <address type='pci' domain='0x0000' bus='0x07' slot='0x00' function='0x0'/> </controller> <controller type='pci' index='10' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='10' port='0x10'/> <alias name='pci.10'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='11' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='11' port='0x11'/> <alias name='pci.11'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x1'/> </controller> <controller type='virtio-serial' index='0'> <alias name='virtio-serial0'/> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0'/> </controller> <interface type='bridge'> <mac address='52:54:00:0a:24:44'/> <source bridge='br0'/> <target dev='vnet0'/> <model type='vmxnet3'/> <alias name='net0'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </interface> <serial type='pty'> <source path='/dev/pts/0'/> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> <alias name='serial0'/> </serial> <console type='pty' tty='/dev/pts/0'> <source path='/dev/pts/0'/> <target type='serial' port='0'/> <alias name='serial0'/> </console> <channel type='unix'> <source mode='bind' path='/var/lib/libvirt/qemu/channel/target/domain-34-Desktop/org.qemu.guest_agent.0'/> <target type='virtio' name='org.qemu.guest_agent.0' state='connected'/> <alias name='channel0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='mouse' bus='ps2'> <alias name='input0'/> </input> <input type='keyboard' bus='ps2'> <alias name='input1'/> </input> <input type='keyboard' bus='ps2'> <alias name='input2'/> </input> <input type='keyboard' bus='ps2'> <alias name='input3'/> </input> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x47' slot='0x00' function='0x0'/> </source> <alias name='hostdev0'/> <rom file='/mnt/user/domains/vbios/580.dump'/> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x41' slot='0x00' function='0x0'/> </source> <alias name='hostdev1'/> <rom file='/mnt/user/domains/vbios/580a.dump'/> <address type='pci' domain='0x0000' bus='0x04' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x09' slot='0x00' function='0x0'/> </source> <alias name='hostdev2'/> <address type='pci' domain='0x0000' bus='0x05' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x0a' slot='0x00' function='0x0'/> </source> <alias name='hostdev3'/> <address type='pci' domain='0x0000' bus='0x06' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x0b' slot='0x00' function='0x0'/> </source> <alias name='hostdev4'/> <address type='pci' domain='0x0000' bus='0x08' slot='0x00' function='0x0'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x0c' slot='0x00' function='0x0'/> </source> <alias name='hostdev5'/> <address type='pci' domain='0x0000' bus='0x0a' slot='0x00' function='0x0'/> </hostdev> <memballoon model='none'/> </devices> <seclabel type='dynamic' model='dac' relabel='yes'> <label>+0:+100</label> <imagelabel>+0:+100</imagelabel> </seclabel> <qemu:commandline> <qemu:arg value='-usb'/> <qemu:arg value='-device'/> <qemu:arg value='usb-kbd,bus=usb-bus.0'/> <qemu:arg value='-device'/> <qemu:arg value='isa-applesmc,osk=theysayonceyougomacyounevergoback'/> <qemu:arg value='-smbios'/> <qemu:arg value='type=2'/> <qemu:arg value='-cpu'/> <qemu:arg value='IvyBridge,kvm=on,vendor=GenuineIntel,+invtsc,vmware-cpuid-freq=on,+pcid,+ssse3,+sse4.2,+popcnt,+avx,+aes,+xsave,+xsaveopt,check'/> <qemu:arg value='-set'/> <qemu:arg value='device.sata0-0-2.rotation_rate=1'/> <qemu:arg value='-set'/> <qemu:arg value='device.sata0-0-3.rotation_rate=1'/> <qemu:arg value='-set'/> <qemu:arg value='device.sata0-0-4.rotation_rate=1'/> </qemu:commandline> </domain> running Catalina 10.15.4 sending you the config.plist now much appreciated!

I only have what was pulled of of Leoyzen's GitHub page. Just now I attempted to locate it on the web but apparently my google-fu is a bit weak today...

OK so I decided to take the plunge after reading all 21 pages. My assumption was that I could take a perfectly working Catalina vm made with macinabox, mount the clover qcow2 image, trash the clover efi folder, replace with the one from @Leoyzen's github and stand a decent chance of it booting, even with no alternations to the xml. Well that didn't happen. I am able to get to the oc boot selector, but regardless of what is selected, the result is the same. This happens almost instantaneously after the boot selector. I also tried another OC.qcow2 image that was uploaded in this thread and the result was the same. Not sure where to go from here. Maybe I'm missing something obvious? Anything I can provide to help in troubleshooting?

I still have them. Pm me and we can figure out logistics

128gb ecc. 96gb for a vm, the rest for dockers and things
