[Support] Nodiaque - Gameserver docker

[Nodiaque]

Summary: Support Thread for Nodiaque Gameserver Dockers

Application: SteamCMD

DockerHub: https://hub.docker.com/r/nodiaque/steamcmd



All dockers are easy to set up and are highly customizable, all dockers are tested with the standard configuration (port forwarding,...) if the are reachable and show up in the server list form the "outside".



The default password for the gameservers if enabled is: Docker

It there is a admin password the default password is: adminDocker



Please read the discription of each docker and the variables that you install (some dockers need special variables to run).



The Steam Username and Password is only needed in templates where the two fields are marked as required with the red *



Special thanks to @ich777 that created the original docker and supported them for many years.



Edited January 29 by Nodiaque

[Nodiaque]

Dockers Available



SteamCMD DedicatedServers:

  - Enshrouded

  - Enshrouded_Proton (experimental)

Edited February 4 by Nodiaque

[Markyb0y]

This is just what I have been looking for....



any idea how long it takes to get approved and to show up?

[Nodiaque]

normally about 2 hours. But since it's my first time submission, I'm not sure if there's an added time

[Bushibot]

5 minutes ago, Nodiaque said:

normally about 2 hours. But since it's my first time submission, I'm not sure if there's an added time

THANK YOU! I had one up but there was much weirdness with getting a working config file.

[Kalivos]

Appreciate you doing this. I've been struggle bussing to get Enshrouded running on unraid this morning in a way that makes me happy.

[Grimbone]

Thank you for doing this. Will be keeping an eye out for this to show up! 👍

[Munkey]

If you're impatient like me you should be able to mess around with another game server and set up enshrouded with Nodiadue's image.



I used v-rising since I already had the installed.



Go to docker page -> Add Container -> choose game template.

Delete most of the configs and then add the ports you need for this game.



Make sure to change the part where it says repository to: nodiaque/steamcmd:enshrouded



Start it and let it download the game, open server logs and watch, it will eventually start the exe file.

Stop it and go into the unraid console and find the json file for the game (find . -name enshrouded_server.json) and edit that to be what you want.

Start it up again and watch logs, you're looking for the following:

[OnlineProviderSteam] 'Initialize' (up)!
[OnlineProviderSteam] 'JoinOrCreateGame' (up)!
[OnlineProviderSteam] 'SetLobbyData' (up)!
[OnlineProviderSteam] 'JoinLocalPlayers' (up)!
[OnlineProviderSteam] 'ConnectToPeers' (up)!
[OnlineProviderSteam] finished transition from 'Uninitialized' to 'InGame' (current='InGame')!
[Session] 'HostOnline' (up)!
[Session] finished transition from 'Lobby' to 'Host_Online' (current='Host_Online')!





[Nodiaque]

9 minutes ago, Munkey said:

If you're impatient like me you should be able to mess around with another game server and set up enshrouded with Nodiadue's image.



I used v-rising since I already had the installed.



Go to docker page -> Add Container -> choose game template.

Delete most of the configs and then add the ports you need for this game.



Make sure to change the part where it says repository to: nodiaque/steamcmd:enshrouded



Start it and let it download the game, open server logs and watch, it will eventually start the exe file.

Stop it and go into the unraid console and find the json file for the game (find . -name enshrouded_server.json) and edit that to be what you want.

Start it up again and watch logs, you're looking for the following:

[OnlineProviderSteam] 'Initialize' (up)!
[OnlineProviderSteam] 'JoinOrCreateGame' (up)!
[OnlineProviderSteam] 'SetLobbyData' (up)!
[OnlineProviderSteam] 'JoinLocalPlayers' (up)!
[OnlineProviderSteam] 'ConnectToPeers' (up)!
[OnlineProviderSteam] finished transition from 'Uninitialized' to 'InGame' (current='InGame')!
[Session] 'HostOnline' (up)!
[Session] finished transition from 'Lobby' to 'Host_Online' (current='Host_Online')!





Just take the xml from my github repo and import it.

[Bushibot]

In wander how many folks are just hitting refresh on apps

[Bushibot]

14 minutes ago, Nodiaque said:

Just take the xml from my github repo and import it.

Umm how would you do that for unraid?

[Munkey]

17 minutes ago, Nodiaque said:

Just take the xml from my github repo and import it.



yeah that works too, had to figure out where those are kept first.

/boot/config/plugins/dockerMan/templates-user/

if anyone needs it.

[Munkey]

3 minutes ago, Bushibot said:

Umm how would you do that for unraid?

in Terminal navigate to /boot/config/plugins/dockerMan/templates-user/ create a file called my-enshrouded.xml and paste in the contents from https://github.com/nodiaque/unraid_template/blob/master/nodiaque/enshrouded.xml

[Bushibot]

13 minutes ago, Munkey said:

in Terminal navigate to /boot/config/plugins/dockerMan/templates-user/ create a file called my-enshrouded.xml and paste in the contents from https://github.com/nodiaque/unraid_template/blob/master/nodiaque/enshrouded.xml

Ahh I see thank you, that is working!

[Nodiaque]

20 minutes ago, Bushibot said:

In wander how many folks are just hitting refresh on apps

yeah I don't know why it's not there. I might have done something wrong

[Munkey]

1 minute ago, Nodiaque said:

yeah I don't know why it's not there. I might have done something wrong

I have no idea how any of this works but at least its really easy to import your xml as a fallback. Good luck getting it listed and nice work!

[Nibbles]

Any plans to add fields for SERVER_NAME and _PASSWORD and such? I'm currently testing your XML after having a semi-successful attempt at skinnr's running but I couldn't get it to pick up the config files, (nor could I find them myself) so. Here we go

Could not load resource cache file 'Z:/serverdata/serverfiles/enshrouded_server.krc'. error=file not found
I'm seeing that but also I can't figure out how to set server name so I can search it, I get the HOST ONLINE bit, but I'm unable to find the server. Any thoughts?

Edited January 25 by Nibbles

[Nodiaque]

You have to edit the config file as per the documentation. Right now, I didn't do anything that automatically put var in the config file. The game itself doesn't support any command line to configure stuff. I might in the futur check other ich777 container and see how to edit the file on the fly before the launch of the server. But for now, just edit the json while server is offline (file is created on first launch with default config as per Enshrouded doc) and you'll be good to go. I myself prefer editing the file then editing var because var require docker recompile while file just need a restart. Just a personal preference here.



I've updated my template to show explicitly that the json file need to be edited to change the name and password.

Edited January 25 by Nodiaque

[Nibbles]

2 minutes ago, Nodiaque said:

You have to edit the config file as per the documentation. Right now, I didn't do anything that automatically put var in the config file. The game itself doesn't support any command line to configure stuff. I might in the futur check other ich777 container and see how to edit the file on the fly before the launch of the server. But for now, just edit the json while server is offline (file is created on first launch with default config as per Enshrouded doc) and you'll be good to go. I myself prefer editing the file then editing var because var require docker recompile while file just need a restart. Just a personal preference here.

So I've done that, foudn the json and edited it, ensured it's right etcetc. Booted the server just fine, but I'm unable to find my server via search. Any thoughts?

[Nodiaque]

It might take a while before it shows like other game. Also, be sure to have port forward properly set in your firewall

[Nibbles]

2 minutes ago, Nodiaque said:

It might take a while before it shows like other game. Also, be sure to have port forward properly set in your firewall

[W 00:05:11,924] [savedata] File command of type '13' failed with error: 'file not found'.
[W 00:05:11,930] [savedata] File command of type '14' failed with error: 'file not found'.

I'm seeing this pop up, is it normal or am I missing perms somewhere?

[Nodiaque]

Did you put the path according to your environnement after inserting the template? This error mean it's not able to save. Normally, should see this:



[server] Start Saving
[I 03:08:01,046] [server] Start Saving
[savedata] [I 03:08:01,052] [savedata] Compression of Blob 0x00000000::USER took 67.00 us
Compression of Blob 0x00000000::USER took 67.00 us
MaxClientComponents: 1

Maybe it doesn't work when no player have joined yet

[Nibbles]

2 minutes ago, Nodiaque said:

Did you put the path according to your environnement after inserting the template? This error mean it's not able to save. Normally, should see this:



[server] Start Saving
[I 03:08:01,046] [server] Start Saving
[savedata] [I 03:08:01,052] [savedata] Compression of Blob 0x00000000::USER took 67.00 us
Compression of Blob 0x00000000::USER took 67.00 us
MaxClientComponents: 1

Maybe it doesn't work when no player have joined yet

The xml set pathing and created the folders. I have data in them so I know it's working.

Thing is:


[server] Start Saving
[I 00:10:11,902] [server] Start Saving
[savedata] [I 00:10:11,907] [savedata] Compression of Blob 0x00000000::USER took 114.00 us
Compression of Blob 0x00000000::USER took 114.00 us
MaxClientComponents: 1

I do see that lol I just can't find the server via search TO conect to it lol



[OnlineProviderSteam] finished transition from 'Uninitialized' to 'InGame' (current='InGame')!
[I 00:00:12,553] [OnlineProviderSteam] finished transition from 'Uninitialized' to 'InGame' (current='InGame')!
[Session] 'HostOnline' (up)!
[I 00:00:12,557] [Session] 'HostOnline' (up)!
[Session] finished transition from 'Lobby' to 'Host_Online' (current='Host_Online')!
[I 00:00:12,557] [Session] finished transition from 'Lobby' to 'Host_Online' (current='Host_Online')!

So I mean technically the server is up and running lol

[Nodiaque]

Yeah, there might be too many server adding and we can't see them all. I don't own the game myself but my friend said they see my server, but it was about 30 minutes to an hour after I started it. Now that we are in the evening (at least where I am), there might be many more server popping and the game browser can't keep up. Other then verifying that the query port and game port are properly port forward, I cannot really say. Maybe check the network you used? By default it's bridge since putting a custom network in a template is a very bad idea, but on my end, i'm using a custom network.

Edited January 25 by Nodiaque

[Nibbles]

9 minutes ago, Nodiaque said:

Yeah, there might be too many server adding and we can't see them all. I don't own the game myself but my friend said they see my server, but it was about 30 minutes to an hour after I started it. Now that we are in the evening (at least where I am), there might be many more server popping and the game browser can't keep up. Other then verifying that the query port and game port are properly port forward, I cannot really say. Maybe check the network you used? By default it's bridge since putting a custom network in a template is a very bad idea, but on my end, i'm using a custom network.

Yeah I have it on a custom network as well, I don't mind waiting it out, do you have a log snapshot of what it will look like if someone joins? I do appreciate the expeditious replies and quick thinking you did to spin this up, thank you!
