RiDDiX

strange.... VM Template: CPU Mode: Host Passthrough Inital Memory: Same as Max Memory Max Memory: XXXXX MB Machine: Q35-6.0 BIOS: OVMF USB Controller: 3.0 (qemu XHCI) Is this like your setup?

Same for me... Eventually I will replace my RX580 from my workstation anytime but atm my GT630 just works fine..

<?xml version="1.0" encoding="UTF-8"?> <!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd"> <plist version="1.0"> <dict> <key>ACPI</key> <dict> <key>Add</key> <array> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-PLUG.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-GFX.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-ARPT.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-XGE.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-NVME.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-XHC.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-EC-USBX-DESKTOP.aml</string> </dict> </array> <key>Delete</key> <array/> <key>Patch</key> <array/> <key>Quirks</key> <dict> <key>FadtEnableReset</key> <false/> <key>NormalizeHeaders</key> <false/> <key>RebaseRegions</key> <false/> <key>ResetHwSig</key> <false/> <key>ResetLogoStatus</key> <true/> <key>SyncTableIds</key> <false/> </dict> </dict> <key>Booter</key> <dict> <key>MmioWhitelist</key> <array/> <key>Patch</key> <array/> <key>Quirks</key> <dict> <key>AllowRelocationBlock</key> <false/> <key>AvoidRuntimeDefrag</key> <true/> <key>DevirtualiseMmio</key> <false/> <key>DisableSingleUser</key> <false/> <key>DisableVariableWrite</key> <false/> <key>DiscardHibernateMap</key> <false/> <key>EnableSafeModeSlide</key> <true/> <key>EnableWriteUnprotector</key> <false/> <key>ForceBooterSignature</key> <false/> <key>ForceExitBootServices</key> <false/> <key>ProtectMemoryRegions</key> <false/> <key>ProtectSecureBoot</key> <false/> <key>ProtectUefiServices</key> <false/> <key>ProvideCustomSlide</key> <true/> <key>ProvideMaxSlide</key> <integer>0</integer> <key>RebuildAppleMemoryMap</key> <true/> <key>SetupVirtualMap</key> <true/> <key>SignalAppleOS</key> <false/> <key>SyncRuntimePermissions</key> <true/> </dict> </dict> <key>DeviceProperties</key> <dict> <key>Add</key> <dict/> <key>Delete</key> <dict/> </dict> <key>Kernel</key> <dict> <key>Add</key> <array> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>Lilu.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/Lilu</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>WhateverGreen.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/WhateverGreen</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>BlueToolFixup.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/BlueToolFixup</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>AppleALC.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/AppleALC</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>RestrictEvents.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/RestrictEvents</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> </array> <key>Block</key> <array/> <key>Emulate</key> <dict> <key>Cpuid1Data</key> <data>VwYFAAAAAAAAAAAAAAAAAA==</data> <key>Cpuid1Mask</key> <data>/////wAAAAAAAAAAAAAAAA==</data> <key>DummyPowerManagement</key> <false/> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> </dict> <key>Force</key> <array/> <key>Patch</key> <array/> <key>Quirks</key> <dict> <key>AppleCpuPmCfgLock</key> <false/> <key>AppleXcpmCfgLock</key> <false/> <key>AppleXcpmExtraMsrs</key> <false/> <key>AppleXcpmForceBoost</key> <false/> <key>CustomSMBIOSGuid</key> <false/> <key>DisableIoMapper</key> <false/> <key>DisableLinkeditJettison</key> <true/> <key>DisableRtcChecksum</key> <false/> <key>ExtendBTFeatureFlags</key> <false/> <key>ExternalDiskIcons</key> <false/> <key>ForceSecureBootScheme</key> <false/> <key>IncreasePciBarSize</key> <false/> <key>LapicKernelPanic</key> <false/> <key>LegacyCommpage</key> <false/> <key>PanicNoKextDump</key> <false/> <key>PowerTimeoutKernelPanic</key> <false/> <key>ProvideCurrentCpuInfo</key> <true/> <key>SetApfsTrimTimeout</key> <integer>-1</integer> <key>ThirdPartyDrives</key> <false/> <key>XhciPortLimit</key> <false/> </dict> <key>Scheme</key> <dict> <key>CustomKernel</key> <false/> <key>FuzzyMatch</key> <true/> <key>KernelArch</key> <string>x86_64</string> <key>KernelCache</key> <string>Auto</string> </dict> </dict> <key>Misc</key> <dict> <key>BlessOverride</key> <array/> <key>Boot</key> <dict> <key>ConsoleAttributes</key> <integer>0</integer> <key>HibernateMode</key> <string>None</string> <key>HideAuxiliary</key> <false/> <key>LauncherOption</key> <string>Disabled</string> <key>LauncherPath</key> <string>Default</string> <key>PickerAttributes</key> <integer>1</integer> <key>PickerAudioAssist</key> <false/> <key>PickerMode</key> <string>Builtin</string> <key>PickerVariant</key> <string>chris1111\ApplePark-2</string> <key>PollAppleHotKeys</key> <false/> <key>ShowPicker</key> <true/> <key>TakeoffDelay</key> <integer>0</integer> <key>Timeout</key> <integer>5</integer> </dict> <key>Debug</key> <dict> <key>AppleDebug</key> <true/> <key>ApplePanic</key> <true/> <key>DisableWatchDog</key> <true/> <key>DisplayDelay</key> <integer>0</integer> <key>DisplayLevel</key> <integer>2147483648</integer> <key>SerialInit</key> <false/> <key>SysReport</key> <false/> <key>Target</key> <integer>3</integer> </dict> <key>Entries</key> <array/> <key>Security</key> <dict> <key>AllowNvramReset</key> <true/> <key>AllowSetDefault</key> <true/> <key>AllowToggleSip</key> <false/> <key>ApECID</key> <integer>0</integer> <key>AuthRestart</key> <false/> <key>BlacklistAppleUpdate</key> <true/> <key>DmgLoading</key> <string>Signed</string> <key>EnablePassword</key> <false/> <key>ExposeSensitiveData</key> <integer>6</integer> <key>HaltLevel</key> <integer>2147483648</integer> <key>PasswordHash</key> <data></data> <key>PasswordSalt</key> <data></data> <key>ScanPolicy</key> <integer>0</integer> <key>SecureBootModel</key> <string>Disabled</string> <key>Vault</key> <string>Optional</string> </dict> <key>Tools</key> <array/> </dict> <key>NVRAM</key> <dict> <key>Add</key> <dict> <key>4D1EDE05-38C7-4A6A-9CC6-4BCCA8B38C14</key> <dict> <key>DefaultBackgroundColor</key> <data>AAAAAA==</data> <key>UIScale</key> <data>AQ==</data> </dict> <key>4D1FDA02-38C7-4A6A-9CC6-4BCCA8B30102</key> <dict> <key>revcpu</key> <integer>1</integer> <key>rtc-blacklist</key> <data></data> </dict> <key>7C436110-AB2A-4BBB-A880-FE41995C9F82</key> <dict> <key>ForceDisplayRotationInEFI</key> <integer>50</integer> <key>SystemAudioVolume</key> <data>Rg==</data> <key>boot-args</key> <string>-v keepsyms=1 debug=0x100 alcid=1</string> <key>csr-active-config</key> <data>7w8AAA==</data> <key>run-efi-updater</key> <string>No</string> </dict> </dict> <key>Delete</key> <dict> <key>4D1EDE05-38C7-4A6A-9CC6-4BCCA8B38C14</key> <array> <string>UIScale</string> <string>DefaultBackgroundColor</string> </array> <key>4D1FDA02-38C7-4A6A-9CC6-4BCCA8B30102</key> <array> <string>rtc-blacklist</string> </array> <key>7C436110-AB2A-4BBB-A880-FE41995C9F82</key> <array> <string>boot-args</string> <string>ForceDisplayRotationInEFI</string> </array> </dict> <key>LegacyEnable</key> <false/> <key>LegacyOverwrite</key> <false/> <key>LegacySchema</key> <dict> <key>7C436110-AB2A-4BBB-A880-FE41995C9F82</key> <array> <string>EFILoginHiDPI</string> <string>EFIBluetoothDelay</string> <string>LocationServicesEnabled</string> <string>SystemAudioVolume</string> <string>SystemAudioVolumeDB</string> <string>SystemAudioVolumeSaved</string> <string>bluetoothActiveControllerInfo</string> <string>bluetoothInternalControllerInfo</string> <string>flagstate</string> <string>fmm-computer-name</string> <string>fmm-mobileme-token-FMM</string> <string>fmm-mobileme-token-FMM-BridgeHasAccount</string> <string>nvda_drv</string> <string>prev-lang:kbd</string> </array> <key>8BE4DF61-93CA-11D2-AA0D-00E098032B8C</key> <array> <string>Boot0080</string> <string>Boot0081</string> <string>Boot0082</string> <string>BootNext</string> <string>BootOrder</string> </array> </dict> <key>WriteFlash</key> <true/> </dict> <key>PlatformInfo</key> <dict> <key>Automatic</key> <true/> <key>CustomMemory</key> <false/> <key>Generic</key> <dict> PASTE HERE YOUR PLATFORM INFO!!! PASTE HERE YOUR PLATFORM INFO!!! PASTE HERE YOUR PLATFORM INFO!!! PASTE HERE YOUR PLATFORM INFO!!! PASTE HERE YOUR PLATFORM INFO!!! PASTE HERE YOUR PLATFORM INFO!!! PASTE HERE YOUR PLATFORM INFO!!! PASTE HERE YOUR PLATFORM INFO!!! PASTE HERE YOUR PLATFORM INFO!!! </dict> <key>UpdateDataHub</key> <true/> <key>UpdateNVRAM</key> <true/> <key>UpdateSMBIOS</key> <true/> <key>UpdateSMBIOSMode</key> <string>Create</string> <key>UseRawUuidEncoding</key> <false/> </dict> <key>UEFI</key> <dict> <key>APFS</key> <dict> <key>EnableJumpstart</key> <true/> <key>GlobalConnect</key> <false/> <key>HideVerbose</key> <true/> <key>JumpstartHotPlug</key> <false/> <key>MinDate</key> <integer>0</integer> <key>MinVersion</key> <integer>0</integer> </dict> <key>AppleInput</key> <dict> <key>AppleEvent</key> <string>Builtin</string> <key>CustomDelays</key> <false/> <key>GraphicsInputMirroring</key> <false/> <key>KeyInitialDelay</key> <integer>0</integer> <key>KeySubsequentDelay</key> <integer>5</integer> <key>PointerSpeedDiv</key> <integer>1</integer> <key>PointerSpeedMul</key> <integer>1</integer> </dict> <key>Audio</key> <dict> <key>AudioCodec</key> <integer>0</integer> <key>AudioDevice</key> <string>PciRoot(0x0)/Pci(0x1b,0x0)</string> <key>AudioOut</key> <integer>0</integer> <key>AudioSupport</key> <false/> <key>MinimumVolume</key> <integer>20</integer> <key>PlayChime</key> <string>Auto</string> <key>ResetTrafficClass</key> <false/> <key>SetupDelay</key> <integer>0</integer> <key>VolumeAmplifier</key> <integer>0</integer> </dict> <key>ConnectDrivers</key> <true/> <key>Drivers</key> <array> <dict> <key>Arguments</key> <string></string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>AudioDxe.efi</string> </dict> <dict> <key>Arguments</key> <string></string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>OpenCanopy.efi</string> </dict> <dict> <key>Arguments</key> <string></string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>OpenHfsPlus.efi</string> </dict> <dict> <key>Arguments</key> <string></string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>OpenRuntime.efi</string> </dict> </array> <key>Input</key> <dict> <key>KeyFiltering</key> <false/> <key>KeyForgetThreshold</key> <integer>5</integer> <key>KeySupport</key> <true/> <key>KeySupportMode</key> <string>Auto</string> <key>KeySwap</key> <false/> <key>PointerSupport</key> <false/> <key>PointerSupportMode</key> <string>ASUS</string> <key>TimerResolution</key> <integer>50000</integer> </dict> <key>Output</key> <dict> <key>ClearScreenOnModeSwitch</key> <false/> <key>ConsoleMode</key> <string></string> <key>DirectGopRendering</key> <false/> <key>ForceResolution</key> <false/> <key>GopPassThrough</key> <string>Disabled</string> <key>IgnoreTextInGraphics</key> <false/> <key>ProvideConsoleGop</key> <true/> <key>ReconnectOnResChange</key> <false/> <key>ReplaceTabWithSpace</key> <false/> <key>Resolution</key> <string>Max</string> <key>SanitiseClearScreen</key> <false/> <key>TextRenderer</key> <string>BuiltinGraphics</string> <key>UgaPassThrough</key> <false/> </dict> <key>ProtocolOverrides</key> <dict> <key>AppleAudio</key> <false/> <key>AppleBootPolicy</key> <false/> <key>AppleDebugLog</key> <false/> <key>AppleEg2Info</key> <false/> <key>AppleFramebufferInfo</key> <false/> <key>AppleImageConversion</key> <false/> <key>AppleImg4Verification</key> <false/> <key>AppleKeyMap</key> <false/> <key>AppleRtcRam</key> <false/> <key>AppleSecureBoot</key> <false/> <key>AppleSmcIo</key> <false/> <key>AppleUserInterfaceTheme</key> <false/> <key>DataHub</key> <false/> <key>DeviceProperties</key> <false/> <key>FirmwareVolume</key> <false/> <key>HashServices</key> <false/> <key>OSInfo</key> <false/> <key>UnicodeCollation</key> <false/> </dict> <key>Quirks</key> <dict> <key>ActivateHpetSupport</key> <false/> <key>DisableSecurityPolicy</key> <false/> <key>EnableVectorAcceleration</key> <true/> <key>ExitBootServicesDelay</key> <integer>0</integer> <key>ForceOcWriteFlash</key> <false/> <key>ForgeUefiSupport</key> <false/> <key>IgnoreInvalidFlexRatio</key> <false/> <key>ReleaseUsbOwnership</key> <false/> <key>ReloadOptionRoms</key> <false/> <key>RequestBootVarRouting</key> <true/> <key>TscSyncTimeout</key> <integer>0</integer> <key>UnblockFsConnect</key> <false/> </dict> <key>ReservedMemory</key> <array/> </dict> </dict> </plist> I marked the section where you can put your PlatformInfos "Generci" once, just look up for "PASTE HERE YOUR PLATFORM INFO!!!" And you should able to got into the installation menu. I use and used OpenCore 0.7.5 and also the mentioned kexts within the config.plist. @ghost82 You are right he need to use the kepler-patcher like I needed But as always try this config.plist also with my mentioned updates to your xml. I hope you'll get to your "Installation Menu". If not I still try to assist you 🙂

This seems to be your gpu part right? Edit it like this: MacOS can be really annoying if something isnt set up correctly. ÄHHHMMMM <type arch='x86_64' machine='pc-q35-6.1'>hvm</type> please change this to: <type arch='x86_64' machine='pc-q35-6.0'>hvm</type> __________ Also remove this line completly: <topology sockets='1' dies='1' cores='2' threads='2'/> Then it nearly looks like this: <?xml version='1.0' encoding='UTF-8'?> <domain type='kvm' xmlns:qemu='http://libvirt.org/schemas/domain/qemu/1.0'> <name>MacPro</name> <uuid>XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX</uuid> <metadata> <vmtemplate xmlns="unraid" name="FreeBSD" icon="freebsd.png" os="freebsd"/> </metadata> <memory unit='KiB'>8388608</memory> <currentMemory unit='KiB'>8388608</currentMemory> <memoryBacking> <nosharepages/> </memoryBacking> <vcpu placement='static'>4</vcpu> <cputune> <vcpupin vcpu='0' cpuset='5'/> <vcpupin vcpu='1' cpuset='17'/> <vcpupin vcpu='2' cpuset='7'/> <vcpupin vcpu='3' cpuset='19'/> </cputune> <os> <type arch='x86_64' machine='pc-q35-6.0'>hvm</type> <loader readonly='yes' type='pflash'>/usr/share/qemu/ovmf-x64/OVMF_CODE-pure-efi.fd</loader> <nvram>/etc/libvirt/qemu/nvram/XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX_VARS-pure-efi.fd</nvram> <boot dev='hd'/> </os> <features> <acpi/> <apic/> </features> <cpu mode='host-passthrough' check='none' migratable='on'> <cache mode='passthrough'/> <feature policy='require' name='topoext'/> </cpu> <clock offset='utc'> <timer name='rtc' tickpolicy='catchup'/> <timer name='pit' tickpolicy='delay'/> <timer name='hpet' present='no'/> </clock> <on_poweroff>destroy</on_poweroff> <on_reboot>restart</on_reboot> <on_crash>restart</on_crash> <devices> <emulator>/usr/local/sbin/qemu</emulator> <disk type='file' device='disk'> <driver name='qemu' type='raw' cache='writeback'/> <source file='/mnt/user/isos/osx/img_monterey.img'/> <target dev='hdd' bus='sata'/> <address type='drive' controller='0' bus='0' target='0' unit='3'/> </disk> <controller type='usb' index='0' model='ich9-ehci1'> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x7'/> </controller> <controller type='usb' index='0' model='ich9-uhci1'> <master startport='0'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x0' multifunction='on'/> </controller> <controller type='usb' index='0' model='ich9-uhci2'> <master startport='2'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x1'/> </controller> <controller type='usb' index='0' model='ich9-uhci3'> <master startport='4'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x07' function='0x2'/> </controller> <controller type='pci' index='0' model='pcie-root'/> <controller type='pci' index='1' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='1' port='0x8'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x0' multifunction='on'/> </controller> <controller type='pci' index='2' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='2' port='0x9'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x1'/> </controller> <controller type='pci' index='3' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='3' port='0xb'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x3'/> </controller> <controller type='pci' index='4' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='4' port='0x12'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x2'/> </controller> <controller type='pci' index='5' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='5' port='0x13'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x3'/> </controller> <controller type='pci' index='6' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='6' port='0x14'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x02' function='0x4'/> </controller> <controller type='pci' index='7' model='pcie-root-port'> <model name='pcie-root-port'/> <target chassis='7' port='0xa'/> <address type='pci' domain='0x0000' bus='0x00' slot='0x01' function='0x2'/> </controller> <controller type='pci' index='8' model='pcie-to-pci-bridge'> <model name='pcie-pci-bridge'/> <address type='pci' domain='0x0000' bus='0x01' slot='0x00' function='0x0'/> </controller> <controller type='virtio-serial' index='0'> <address type='pci' domain='0x0000' bus='0x03' slot='0x00' function='0x0'/> </controller> <controller type='sata' index='0'> <address type='pci' domain='0x0000' bus='0x00' slot='0x1f' function='0x2'/> </controller> <interface type='bridge'> <mac address='XXXXXXXXXXXXXXXXXXXXXXXXXXXXXX'/> <source bridge='br0'/> <model type='e1000'/> <address type='pci' domain='0x0000' bus='0x08' slot='0x01' function='0x0'/> </interface> <serial type='pty'> <target type='isa-serial' port='0'> <model name='isa-serial'/> </target> </serial> <console type='pty'> <target type='serial' port='0'/> </console> <channel type='unix'> <target type='virtio' name='org.qemu.guest_agent.0'/> <address type='virtio-serial' controller='0' bus='0' port='1'/> </channel> <input type='tablet' bus='usb'> <address type='usb' bus='0' port='1'/> </input> <input type='mouse' bus='ps2'/> <input type='keyboard' bus='ps2'/> <audio id='1' type='none'/> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x25' slot='0x00' function='0x0'/> </source> <rom file='/mnt/user/isos/vbios/gt710.rom'/> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x0' multifunction='on'/> </hostdev> <hostdev mode='subsystem' type='pci' managed='yes'> <driver name='vfio'/> <source> <address domain='0x0000' bus='0x25' slot='0x00' function='0x1'/> </source> <address type='pci' domain='0x0000' bus='0x02' slot='0x00' function='0x1'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x17ef'/> <product id='0x6039'/> </source> <address type='usb' bus='0' port='3'/> </hostdev> <hostdev mode='subsystem' type='usb' managed='no'> <source> <vendor id='0x1a2c'/> <product id='0x0e24'/> </source> <address type='usb' bus='0' port='4'/> </hostdev> <memballoon model='none'/> </devices> <qemu:commandline> <qemu:arg value='-device'/> <qemu:arg value='isa-applesmc,osk=xxxxxxxxxxxxxxxxxxxxxxxxxxxxxx'/> <qemu:arg value='-smbios'/> <qemu:arg value='type=2'/> <qemu:arg value='-cpu'/> <qemu:arg value='host,vendor=GenuineIntel,+invtsc,kvm=on'/> </qemu:commandline> </domain>

You should also got a PM 🙂 Sorry for my absence...

For me it seems to do with 3D Acceleration. I dont know why. But for me it happens when I opened Firefox or any other programm which use hardware accelerations... And it not freezing instand it just need a few minutes... I dont know why...

As @ghost82 already mentioned it right you dont need VirtualsSMC.kext with my settings 🙂

For me it is a lil bit of nastynes cuz Unraid will when upgraded to stable 6.10 maybe remove the patched / updated files. So why I should do it myself, when already a update will come which add the wanted "features"? I mostly like to use a system like it is (system as is). Just for better error findings and so on. 🙂 I wont say that the "new prebuilt binaries" are bad or something near like this. It is nice that someone found a way to do it for earlier unraid builds but as I said, if some new errors or problems can come through such doings no one can really help if they happen or I will say it will just be harder to find solutions then.

Ups yeah sorry forgot to mention it.

I used nearly the same guid for creating the usb installer, but I used Big Sur then upgraded to Monterey. If you are able to passthrough a usb card or even the onboard usb controller to the vm I should work just fine. Its what I did. I created the usb installer within a linux vm, then passthrough my usb onboard to the mac vm, I used FreeBSD as template for my hackintosh vm, added the qemu arg lines (at the bottom of my xml) and edited my xml for my gpu to be paired instead of splitted, keyword "multifunction=on". Then I added the kexts which I needed for my Hackintosh VM. Lilu and Whatevergreen also RestrictEvents are needed in most of the cases. My VM runs smoth and nicely, for me the badside is that my Unraid Server atm is stuck with a GT630 so I needed the geforce-kepler patcher from chris1111 which added the needed geforce kexts to get my monitor looking correct and full resolution.

It seems that the "LATEST" isnt the LATEST This is why I added the :master Because it uses NordVPN Client 3.11 instead 3.10

If you want you can already install latest Test Version of unraid: https://s3.amazonaws.com/dnld.lime-technology.com/test/unRAIDServer.plg OVMF TMP already there without any nasty patches. 🙂

As ghost wrote it already. The bootarg still works as it should and as you see. Your monitor just freezed up where Unraid stopped using your monitor. (Like a frozen Picture)

ASRock X570 Phantom Gaming 4S no problems here. Try to update your BIOS'es maybe?

Found a fix: Edit the docker template and add/replace for repository: bubuntux/nordvpn:master Start the container, when stuck at "connecting" Go into Unraid -> Docker -> Click on nordvpn Icon -> Console -> type curl ifconfig.io Check IP against your WAN-IP. Should work 🙂

I try now a few and check which one is my favorite. Here my Logs / Username and Password wont show. But it is stuck at connecting -.-

So I tried with chaning my password within nordvpn control panel.. Dont work So Ill go back to an other nordvpn docker....

Ok. I will try this also but afaik if this happens every week it seems nearly useless. Because why should I change my Password every week?

Post your diagnotic log file or try to check your network settings within Unraid.

I dont know if I am supposed to post a 6.10.0-rc2h Build here... But with this no "external" Patches are needed. Decided to do because it is visible within the forums itself: https://s3.amazonaws.com/dnld.lime-technology.com/test/unRAIDServer.plg This will bring into the "Test"-Branche but you will be able to get the "OVMF TPM"-BIOS. Just edit then your xml or from the drop down menu..

Also for me since last night completly broken. Used an other one... Sad cuz NordLynx and KillSwitch worked great till yesterday night.

<?xml version="1.0" encoding="UTF-8"?> <!DOCTYPE plist PUBLIC "-//Apple//DTD PLIST 1.0//EN" "http://www.apple.com/DTDs/PropertyList-1.0.dtd"> <plist version="1.0"> <dict> <key>ACPI</key> <dict> <key>Add</key> <array> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-PLUG.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-GFX.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-ARPT.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-XGE.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-NVME.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-XHC.aml</string> </dict> <dict> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>SSDT-EC-USBX-DESKTOP.aml</string> </dict> </array> <key>Delete</key> <array/> <key>Patch</key> <array/> <key>Quirks</key> <dict> <key>FadtEnableReset</key> <false/> <key>NormalizeHeaders</key> <false/> <key>RebaseRegions</key> <false/> <key>ResetHwSig</key> <false/> <key>ResetLogoStatus</key> <true/> <key>SyncTableIds</key> <false/> </dict> </dict> <key>Booter</key> <dict> <key>MmioWhitelist</key> <array/> <key>Patch</key> <array/> <key>Quirks</key> <dict> <key>AllowRelocationBlock</key> <false/> <key>AvoidRuntimeDefrag</key> <true/> <key>DevirtualiseMmio</key> <false/> <key>DisableSingleUser</key> <false/> <key>DisableVariableWrite</key> <false/> <key>DiscardHibernateMap</key> <false/> <key>EnableSafeModeSlide</key> <true/> <key>EnableWriteUnprotector</key> <false/> <key>ForceBooterSignature</key> <false/> <key>ForceExitBootServices</key> <false/> <key>ProtectMemoryRegions</key> <false/> <key>ProtectSecureBoot</key> <false/> <key>ProtectUefiServices</key> <false/> <key>ProvideCustomSlide</key> <true/> <key>ProvideMaxSlide</key> <integer>0</integer> <key>RebuildAppleMemoryMap</key> <true/> <key>SetupVirtualMap</key> <true/> <key>SignalAppleOS</key> <false/> <key>SyncRuntimePermissions</key> <true/> </dict> </dict> <key>DeviceProperties</key> <dict> <key>Add</key> <dict/> <key>Delete</key> <dict/> </dict> <key>Kernel</key> <dict> <key>Add</key> <array> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>Lilu.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/Lilu</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>WhateverGreen.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/WhateverGreen</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>BlueToolFixup.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/BlueToolFixup</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>AppleALC.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/AppleALC</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> <dict> <key>Arch</key> <string>Any</string> <key>BundlePath</key> <string>RestrictEvents.kext</string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>ExecutablePath</key> <string>Contents/MacOS/RestrictEvents</string> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> <key>PlistPath</key> <string>Contents/Info.plist</string> </dict> </array> <key>Block</key> <array/> <key>Emulate</key> <dict> <key>Cpuid1Data</key> <data>VwYFAAAAAAAAAAAAAAAAAA==</data> <key>Cpuid1Mask</key> <data>/////wAAAAAAAAAAAAAAAA==</data> <key>DummyPowerManagement</key> <false/> <key>MaxKernel</key> <string></string> <key>MinKernel</key> <string></string> </dict> <key>Force</key> <array/> <key>Patch</key> <array/> <key>Quirks</key> <dict> <key>AppleCpuPmCfgLock</key> <false/> <key>AppleXcpmCfgLock</key> <false/> <key>AppleXcpmExtraMsrs</key> <false/> <key>AppleXcpmForceBoost</key> <false/> <key>CustomSMBIOSGuid</key> <false/> <key>DisableIoMapper</key> <false/> <key>DisableLinkeditJettison</key> <true/> <key>DisableRtcChecksum</key> <false/> <key>ExtendBTFeatureFlags</key> <false/> <key>ExternalDiskIcons</key> <false/> <key>ForceSecureBootScheme</key> <false/> <key>IncreasePciBarSize</key> <false/> <key>LapicKernelPanic</key> <false/> <key>LegacyCommpage</key> <false/> <key>PanicNoKextDump</key> <false/> <key>PowerTimeoutKernelPanic</key> <false/> <key>ProvideCurrentCpuInfo</key> <true/> <key>SetApfsTrimTimeout</key> <integer>-1</integer> <key>ThirdPartyDrives</key> <false/> <key>XhciPortLimit</key> <false/> </dict> <key>Scheme</key> <dict> <key>CustomKernel</key> <false/> <key>FuzzyMatch</key> <true/> <key>KernelArch</key> <string>x86_64</string> <key>KernelCache</key> <string>Auto</string> </dict> </dict> <key>Misc</key> <dict> <key>BlessOverride</key> <array/> <key>Boot</key> <dict> <key>ConsoleAttributes</key> <integer>0</integer> <key>HibernateMode</key> <string>None</string> <key>HideAuxiliary</key> <false/> <key>LauncherOption</key> <string>Disabled</string> <key>LauncherPath</key> <string>Default</string> <key>PickerAttributes</key> <integer>1</integer> <key>PickerAudioAssist</key> <false/> <key>PickerMode</key> <string>Builtin</string> <key>PickerVariant</key> <string>Acidanthera\Syrah</string> <key>PollAppleHotKeys</key> <false/> <key>ShowPicker</key> <true/> <key>TakeoffDelay</key> <integer>0</integer> <key>Timeout</key> <integer>5</integer> </dict> <key>Debug</key> <dict> <key>AppleDebug</key> <true/> <key>ApplePanic</key> <true/> <key>DisableWatchDog</key> <true/> <key>DisplayDelay</key> <integer>0</integer> <key>DisplayLevel</key> <integer>2147483648</integer> <key>SerialInit</key> <false/> <key>SysReport</key> <false/> <key>Target</key> <integer>3</integer> </dict> <key>Entries</key> <array/> <key>Security</key> <dict> <key>AllowNvramReset</key> <true/> <key>AllowSetDefault</key> <true/> <key>AllowToggleSip</key> <false/> <key>ApECID</key> <integer>0</integer> <key>AuthRestart</key> <false/> <key>BlacklistAppleUpdate</key> <true/> <key>DmgLoading</key> <string>Signed</string> <key>EnablePassword</key> <false/> <key>ExposeSensitiveData</key> <integer>6</integer> <key>HaltLevel</key> <integer>2147483648</integer> <key>PasswordHash</key> <data></data> <key>PasswordSalt</key> <data></data> <key>ScanPolicy</key> <integer>0</integer> <key>SecureBootModel</key> <string>Disabled</string> <key>Vault</key> <string>Optional</string> </dict> <key>Tools</key> <array/> </dict> <key>NVRAM</key> <dict> <key>Add</key> <dict> <key>4D1EDE05-38C7-4A6A-9CC6-4BCCA8B38C14</key> <dict> <key>DefaultBackgroundColor</key> <data>AAAAAA==</data> <key>UIScale</key> <data>AQ==</data> </dict> <key>4D1FDA02-38C7-4A6A-9CC6-4BCCA8B30102</key> <dict> <key>revcpu</key> <integer>1</integer> <key>rtc-blacklist</key> <data></data> </dict> <key>7C436110-AB2A-4BBB-A880-FE41995C9F82</key> <dict> <key>ForceDisplayRotationInEFI</key> <integer>50</integer> <key>SystemAudioVolume</key> <data>Rg==</data> <key>boot-args</key> <string>-v keepsyms=1 debug=0x100 alcid=1</string> <key>csr-active-config</key> <data>7w8AAA==</data> <key>run-efi-updater</key> <string>No</string> </dict> </dict> <key>Delete</key> <dict> <key>4D1EDE05-38C7-4A6A-9CC6-4BCCA8B38C14</key> <array> <string>UIScale</string> <string>DefaultBackgroundColor</string> </array> <key>4D1FDA02-38C7-4A6A-9CC6-4BCCA8B30102</key> <array> <string>rtc-blacklist</string> </array> <key>7C436110-AB2A-4BBB-A880-FE41995C9F82</key> <array> <string>boot-args</string> <string>ForceDisplayRotationInEFI</string> </array> </dict> <key>LegacyEnable</key> <false/> <key>LegacyOverwrite</key> <false/> <key>LegacySchema</key> <dict> <key>7C436110-AB2A-4BBB-A880-FE41995C9F82</key> <array> <string>EFILoginHiDPI</string> <string>EFIBluetoothDelay</string> <string>LocationServicesEnabled</string> <string>SystemAudioVolume</string> <string>SystemAudioVolumeDB</string> <string>SystemAudioVolumeSaved</string> <string>bluetoothActiveControllerInfo</string> <string>bluetoothInternalControllerInfo</string> <string>flagstate</string> <string>fmm-computer-name</string> <string>fmm-mobileme-token-FMM</string> <string>fmm-mobileme-token-FMM-BridgeHasAccount</string> <string>nvda_drv</string> <string>prev-lang:kbd</string> </array> <key>8BE4DF61-93CA-11D2-AA0D-00E098032B8C</key> <array> <string>Boot0080</string> <string>Boot0081</string> <string>Boot0082</string> <string>BootNext</string> <string>BootOrder</string> </array> </dict> <key>WriteFlash</key> <true/> </dict> <key>PlatformInfo</key> <dict> <key>Automatic</key> <true/> <key>CustomMemory</key> <false/> <key>Generic</key> <dict> </dict> <key>UpdateDataHub</key> <true/> <key>UpdateNVRAM</key> <true/> <key>UpdateSMBIOS</key> <true/> <key>UpdateSMBIOSMode</key> <string>Create</string> <key>UseRawUuidEncoding</key> <false/> </dict> <key>UEFI</key> <dict> <key>APFS</key> <dict> <key>EnableJumpstart</key> <true/> <key>GlobalConnect</key> <false/> <key>HideVerbose</key> <true/> <key>JumpstartHotPlug</key> <false/> <key>MinDate</key> <integer>0</integer> <key>MinVersion</key> <integer>0</integer> </dict> <key>AppleInput</key> <dict> <key>AppleEvent</key> <string>Builtin</string> <key>CustomDelays</key> <false/> <key>GraphicsInputMirroring</key> <false/> <key>KeyInitialDelay</key> <integer>0</integer> <key>KeySubsequentDelay</key> <integer>5</integer> <key>PointerSpeedDiv</key> <integer>1</integer> <key>PointerSpeedMul</key> <integer>1</integer> </dict> <key>Audio</key> <dict> <key>AudioCodec</key> <integer>0</integer> <key>AudioDevice</key> <string>PciRoot(0x0)/Pci(0x1b,0x0)</string> <key>AudioOut</key> <integer>0</integer> <key>AudioSupport</key> <false/> <key>MinimumVolume</key> <integer>20</integer> <key>PlayChime</key> <string>Auto</string> <key>ResetTrafficClass</key> <false/> <key>SetupDelay</key> <integer>0</integer> <key>VolumeAmplifier</key> <integer>0</integer> </dict> <key>ConnectDrivers</key> <true/> <key>Drivers</key> <array> <dict> <key>Arguments</key> <string></string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>AudioDxe.efi</string> </dict> <dict> <key>Arguments</key> <string></string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>OpenCanopy.efi</string> </dict> <dict> <key>Arguments</key> <string></string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>OpenHfsPlus.efi</string> </dict> <dict> <key>Arguments</key> <string></string> <key>Comment</key> <string></string> <key>Enabled</key> <true/> <key>Path</key> <string>OpenRuntime.efi</string> </dict> </array> <key>Input</key> <dict> <key>KeyFiltering</key> <false/> <key>KeyForgetThreshold</key> <integer>5</integer> <key>KeySupport</key> <true/> <key>KeySupportMode</key> <string>Auto</string> <key>KeySwap</key> <false/> <key>PointerSupport</key> <false/> <key>PointerSupportMode</key> <string>ASUS</string> <key>TimerResolution</key> <integer>50000</integer> </dict> <key>Output</key> <dict> <key>ClearScreenOnModeSwitch</key> <false/> <key>ConsoleMode</key> <string></string> <key>DirectGopRendering</key> <false/> <key>ForceResolution</key> <false/> <key>GopPassThrough</key> <string>Disabled</string> <key>IgnoreTextInGraphics</key> <false/> <key>ProvideConsoleGop</key> <true/> <key>ReconnectOnResChange</key> <false/> <key>ReplaceTabWithSpace</key> <false/> <key>Resolution</key> <string>Max</string> <key>SanitiseClearScreen</key> <false/> <key>TextRenderer</key> <string>BuiltinGraphics</string> <key>UgaPassThrough</key> <false/> </dict> <key>ProtocolOverrides</key> <dict> <key>AppleAudio</key> <false/> <key>AppleBootPolicy</key> <false/> <key>AppleDebugLog</key> <false/> <key>AppleEg2Info</key> <false/> <key>AppleFramebufferInfo</key> <false/> <key>AppleImageConversion</key> <false/> <key>AppleImg4Verification</key> <false/> <key>AppleKeyMap</key> <false/> <key>AppleRtcRam</key> <false/> <key>AppleSecureBoot</key> <false/> <key>AppleSmcIo</key> <false/> <key>AppleUserInterfaceTheme</key> <false/> <key>DataHub</key> <false/> <key>DeviceProperties</key> <false/> <key>FirmwareVolume</key> <false/> <key>HashServices</key> <false/> <key>OSInfo</key> <false/> <key>UnicodeCollation</key> <false/> </dict> <key>Quirks</key> <dict> <key>ActivateHpetSupport</key> <false/> <key>DisableSecurityPolicy</key> <false/> <key>EnableVectorAcceleration</key> <true/> <key>ExitBootServicesDelay</key> <integer>0</integer> <key>ForceOcWriteFlash</key> <false/> <key>ForgeUefiSupport</key> <false/> <key>IgnoreInvalidFlexRatio</key> <false/> <key>ReleaseUsbOwnership</key> <false/> <key>ReloadOptionRoms</key> <false/> <key>RequestBootVarRouting</key> <true/> <key>TscSyncTimeout</key> <integer>0</integer> <key>UnblockFsConnect</key> <false/> </dict> <key>ReservedMemory</key> <array/> </dict> </dict> </plist> Nothing special inside here. Just some kexts which are needed for my hardware... No / less Patches and yeah it just works.. I removed my platform info cuz of ID and s/n. But anyway just my setup. 🙂

It is so sad. That this problem persists without any logs -.- I am getting mad and sad....

I am using "MacPro7,1" as SMBIOS. Because yeah the raw power of my CPU / Cores and RAM. Also I just use OpenCore Configurator when I am lazy. But you should avoid using it. (Mostly atm it breaks things/settings). Also shows your "log" that you malformatted your config.plist (Maybe OpenCore Configurator related).

Nice to read, that now it works 🙂 Sometimes small things make a big difference... BTW my Mac OS Hackintosh VM runs better then my Win 11 VM This is such a strange behaviour XD
