May 25, 20233 yr Thanks, I verified disk and it says disk not zeroed out. Not sure how it even cleared Stage 4 if so.. I am now clearing the disk again starting with pre-read
May 26, 20233 yr Failing again. Feels like something is not right. Doesn’t seem like an issue with the disk? Any idea what’s the issue and how to resolve it? #################################################################################################### # Unraid Server Preclear of disk xxx # # Cycle 1 of 1, partition start on sector 64. # # # # Step 1 of 5 - Pre-read verification: [23:22:47 @ 213 MB/s] SUCCESS # # Step 2 of 5 - Zeroing the disk: [23:23:33 @ 213 MB/s] SUCCESS # # Step 3 of 5 - Writing Unraid's Preclear signature: SUCCESS # # Step 4 of 5 - Verifying Unraid's Preclear signature: SUCCESS # # Step 5 of 5 - Post-Read verification: FAIL # # # # # # # #################################################################################################### # Cycle elapsed time: 47:11:04 | Total elapsed time: 47:11:05 # #################################################################################################### #################################################################################################### # S.M.A.R.T. Status (device type: default) # # # # ATTRIBUTE INITIAL STATUS # # Reallocated_Sector_Ct 0 - # # Power_On_Hours 94 - # # Temperature_Celsius 36 - # # Reallocated_Event_Count 0 - # # Current_Pending_Sector 0 - # # Offline_Uncorrectable 0 - # # UDMA_CRC_Error_Count 0 - # # # # # #################################################################################################### # # #################################################################################################### … May 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 408604901376 bytes (409 GB, 381 GiB) copied, 1449.55 s, 282 MB/sMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 196567+0 records inMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 196566+0 records outMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 412228780032 bytes (412 GB, 384 GiB) copied, 1462.4 s, 282 MB/sMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 198295+0 records inMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 198294+0 records outMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 415852658688 bytes (416 GB, 387 GiB) copied, 1475.27 s, 282 MB/sMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: post-read verification failed!May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Error:May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.:May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: ATTRIBUTE INITIAL NOW STATUSMay 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Reallocated_Sector_Ct 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Power_On_Hours 94 141 Up 47May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Temperature_Celsius 36 51 Up 15May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Reallocated_Event_Count 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Current_Pending_Sector 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Offline_Uncorrectable 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: UDMA_CRC_Error_Count 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: May 26 22:33:25 preclear_disk_xxx_2299: error encountered, exiting ...
May 26, 20233 yr Author 1 hour ago, CyberMew said: Failing again. Feels like something is not right. Doesn’t seem like an issue with the disk? Any idea what’s the issue and how to resolve it? #################################################################################################### # Unraid Server Preclear of disk xxx # # Cycle 1 of 1, partition start on sector 64. # # # # Step 1 of 5 - Pre-read verification: [23:22:47 @ 213 MB/s] SUCCESS # # Step 2 of 5 - Zeroing the disk: [23:23:33 @ 213 MB/s] SUCCESS # # Step 3 of 5 - Writing Unraid's Preclear signature: SUCCESS # # Step 4 of 5 - Verifying Unraid's Preclear signature: SUCCESS # # Step 5 of 5 - Post-Read verification: FAIL # # # # # # # #################################################################################################### # Cycle elapsed time: 47:11:04 | Total elapsed time: 47:11:05 # #################################################################################################### #################################################################################################### # S.M.A.R.T. Status (device type: default) # # # # ATTRIBUTE INITIAL STATUS # # Reallocated_Sector_Ct 0 - # # Power_On_Hours 94 - # # Temperature_Celsius 36 - # # Reallocated_Event_Count 0 - # # Current_Pending_Sector 0 - # # Offline_Uncorrectable 0 - # # UDMA_CRC_Error_Count 0 - # # # # # #################################################################################################### # # #################################################################################################### … May 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 408604901376 bytes (409 GB, 381 GiB) copied, 1449.55 s, 282 MB/sMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 196567+0 records inMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 196566+0 records outMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 412228780032 bytes (412 GB, 384 GiB) copied, 1462.4 s, 282 MB/sMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 198295+0 records inMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 198294+0 records outMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: dd output: 415852658688 bytes (416 GB, 387 GiB) copied, 1475.27 s, 282 MB/sMay 26 22:33:20 preclear_disk_xxx_2299: Post-Read: post-read verification failed!May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Error:May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.:May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: ATTRIBUTE INITIAL NOW STATUSMay 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Reallocated_Sector_Ct 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Power_On_Hours 94 141 Up 47May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Temperature_Celsius 36 51 Up 15May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Reallocated_Event_Count 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Current_Pending_Sector 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: Offline_Uncorrectable 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: UDMA_CRC_Error_Count 0 0 -May 26 22:33:25 preclear_disk_xxx_2299: S.M.A.R.T.: May 26 22:33:25 preclear_disk_xxx_2299: error encountered, exiting ... Try the following: Post your diagnostics and the UD Preclear log so I can see if there is a reason I can find for the failure. Install the Binhex Preclear Docker container. Run UD preclear and select the docker from the dropdown to run the preclear. See if the results are the same.
May 26, 20233 yr My array is currently stopped due to disabled drive and this new drive is supposed to replace that using the drive swap procedure, so unfortunately I can’t start and install the docker and run it.. is there another way to do it? I’ll post the unraid diagnostics once I am able to. How do I get the full UD Preclear log?
May 26, 20233 yr Author 6 minutes ago, CyberMew said: My array is currently stopped due to disabled drive and this new drive is supposed to replace that using the drive swap procedure That drive should be emulated, assuming you have parity, and you can start the array. 8 minutes ago, CyberMew said: I’ll post the unraid diagnostics once I am able to. How do I get the full UD Preclear log? Use 'diagnostics' on a command line to get diagnottics. Preclear log can be downloaded from the UD Preclear page. Click on the download icon.
May 27, 20233 yr 7 hours ago, dlandon said: That drive should be emulated, assuming you have parity, and you can start the array. Use 'diagnostics' on a command line to get diagnottics. Preclear log can be downloaded from the UD Preclear page. Click on the download icon. My disk 5 is unassigned right now with a red X, will it know to emulate disk 5 or remove it and update my parity (losing data)? Also have uploaded the requested logs here: TOWER-unassigned.devices.preclear-20230527-0806.zip tower-diagnostics-20230527-0048.zip
May 27, 20233 yr Author 11 hours ago, CyberMew said: My disk 5 is unassigned right now with a red X, will it know to emulate disk 5 or remove it and update my parity (losing data)? I'm not sure what you've done, but try to start the array and the disk should be emulated.
May 27, 20233 yr On 5/23/2023 at 10:38 AM, CyberMew said: # Step 5 of 5 - Post-Read verification: FAIL # Could be bad RAM
June 1, 20233 yr I tried to preclear using the binhex docker as suggested, and it precleared successfully. So maybe there is some bug with the plugin..? Should I stop preclear and Verify Disk using this plugin, or is the drive good to go now? Quote ================================================================== 1.22 = unRAID server Pre-Clear disk /dev/sdk = cycle 1 of 1, partition start on sector 64 = Disk Pre-Clear-Read completed DONE = Step 1 of 10 - Copying zeros to first 2048k bytes DONE = Step 2 of 10 - Copying zeros to remainder of disk to clear it DONE = Step 3 of 10 - Disk is now cleared from MBR onward. DONE = Step 4 of 10 - Clearing MBR bytes for partition 2,3 & 4 DONE = Step 5 of 10 - Clearing MBR code area DONE = Step 6 of 10 - Setting MBR signature bytes DONE = Step 7 of 10 - Setting partition 1 to precleared state DONE = Step 8 of 10 - Notifying kernel we changed the partitioning DONE = Step 9 of 10 - Creating the /dev/disk/by* entries DONE = Step 10 of 10 - Verifying if the MBR is cleared. DONE = Disk Post-Clear-Read completed DONE Disk Temperature: 56C, Elapsed Time: 101:02:38 ========================================================================1.22 == WDCWD181KFGX-68AFPN0 == Disk /dev/sdk has been successfully precleared == with a starting sector of 64 ============================================================================ ** Changed attributes in files: /tmp/smart_start_sdk /tmp/smart_finish_sdk ATTRIBUTE NEW_VAL OLD_VAL FAILURE_THRESHOLD STATUS RAW_VALUE Temperature_Celsius = 35 53 0 ok 56 No SMART attributes are FAILING_NOW 0 sectors were pending re-allocation before the start of the preclear. 0 sectors were pending re-allocation after pre-read in cycle 1 of 1. 0 sectors were pending re-allocation after zero of disk in cycle 1 of 1. 0 sectors are pending re-allocation at the end of the preclear, the number of sectors pending re-allocation did not change. 0 sectors had been re-allocated before the start of the preclear. 0 sectors are re-allocated at the end of the preclear, the number of sectors re-allocated did not change.
June 1, 20233 yr Author 8 hours ago, CyberMew said: So maybe there is some bug with the plugin..? There have been several reports of post read issues on larger disks. I haven't been able to get enough information to figure out what this might be. That's why I suggested using the docker for your preclear. 8 hours ago, CyberMew said: Should I stop preclear and Verify Disk using this plugin, or is the drive good to go now? The disk should be good to go.
June 1, 20233 yr 5 minutes ago, dlandon said: There have been several reports of post read issues on larger disks. I haven't been able to get enough information to figure out what this might be. That's why I suggested using the docker for your preclear. The disk should be good to go. Thanks for confirming! Hopefully my logs were helpful in helping you figure it out..
June 2, 20233 yr not sure what a sweetalert2 is but i got it.. i have gotten a couple different preclear errors before when i was working with the UD plugin.. i not sure if its due to i doing 3 14TB drives at once.. if its hogging the cpu a i did get 500 error trying to access website so not sure figured id report it before i reboot and try a file to fix my UD warning error i getting tardis-diagnostics-20230602-0856.zip
June 2, 20233 yr Author 9 minutes ago, comet424 said: not sure what a sweetalert2 Sweetalert2 is used for the dialogs used in UD and UD Preclear.
June 2, 20233 yr ah ok.. do you happen to know what caused it? from my diag is it from running 3 Preclears at once that it could be cpu over load.. i was thinking of cpu pinning so the first cpu be just for unraid not sure
June 2, 20233 yr ah ok i know it doesnt look like the cpu is bogged down least not 100% utlizied but cant afford the more expensive cpus but probably better to use my backupserver later.. it doesnt nothing just waits for copies least be less cpu load yet its only a 2 core cpu for now but i appreciate your plugin it helps to make sure these hard drives are good 🙂
June 2, 20233 yr Author 1 minute ago, comet424 said: ah ok i know it doesnt look like the cpu is bogged down least not 100% utlizied but cant afford the more expensive cpus but probably better to use my backupserver later.. it doesnt nothing just waits for copies least be less cpu load yet its only a 2 core cpu for now but i appreciate your plugin it helps to make sure these hard drives are good 🙂 Doing three preclears at once could be a bit much for a less powerful processor.
June 2, 20233 yr ya thats what i thinking i know i did 2 on the 2 core cpu but i didnt touch it for a week.. so it didnt have an issue my main is AMD Ryzen 7 3700X 8-Core @ 3600 MHz and sure runs other crap lol... i do enjoy the resume feature... the old preclear i used to use a couple years ago i couldnt do a reboot to test other things and then you gotta start from scratch... so love this version 🙂
June 2, 20233 yr my one 14tb drive picked up some read errors in the system log a few hours ago.. after my last post .,... does it say what caused it... like there is no errors on the drive showing and this is the 3rd run of the preclear on step 1... just wanna see what caused it possibly tardis-diagnostics-20230602-1502.zip
June 2, 20233 yr Author Check your cables: Jun 2 11:43:56 Tardis kernel: sd 11:0:7:0: [sdk] tag#3115 UNKNOWN(0x2003) Result: hostbyte=0x0b driverbyte=DRIVER_OK cmd_age=0s Jun 2 11:43:56 Tardis kernel: sd 11:0:7:0: [sdk] tag#3115 CDB: opcode=0x88 88 00 00 00 00 00 8b c8 1e 08 00 00 05 70 00 00 Jun 2 11:43:56 Tardis kernel: I/O error, dev sdk, sector 2345147912 op 0x0:(READ) flags 0x84700 phys_seg 128 prio class 0 Jun 2 11:43:56 Tardis kernel: sd 11:0:7:0: [sdk] tag#3121 UNKNOWN(0x2003) Result: hostbyte=0x0b driverbyte=DRIVER_OK cmd_age=0s Jun 2 11:43:56 Tardis kernel: sd 11:0:7:0: [sdk] tag#3121 CDB: opcode=0x88 88 00 00 00 00 00 8b c8 28 00 00 00 02 00 00 00 Jun 2 11:43:56 Tardis kernel: I/O error, dev sdk, sector 2345150464 op 0x0:(READ) flags 0x80700 phys_seg 64 prio class 0 Jun 2 11:43:56 Tardis kernel: sd 11:0:7:0: [sdk] tag#3117 UNKNOWN(0x2003) Result: hostbyte=0x0b driverbyte=DRIVER_OK cmd_age=0s Jun 2 11:43:56 Tardis kernel: sd 11:0:7:0: [sdk] tag#3117 CDB: opcode=0x88 88 00 00 00 00 00 8b c8 24 00 00 00 04 00 00 00 Jun 2 11:43:56 Tardis kernel: I/O error, dev sdk, sector 2345149440 op 0x0:(READ) flags 0x84700 phys_seg 128 prio class 0 Jun 2 11:43:56 Tardis kernel: sd 11:0:7:0: [sdk] tag#3116 UNKNOWN(0x2003) Result: hostbyte=0x0b driverbyte=DRIVER_OK cmd_age=0s Jun 2 11:43:56 Tardis kernel: sd 11:0:7:0: [sdk] tag#3116 CDB: opcode=0x88 88 00 00 00 00 00 8b c8 23 78 00 00 00 88 00 00 Jun 2 11:43:56 Tardis kernel: I/O error, dev sdk, sector 2345149304 op 0x0:(READ) flags 0x80700 phys_seg 17 prio class 0 Jun 2 11:43:57 Tardis kernel: sd 11:0:7:0: Power-on or device reset occurred
June 2, 20233 yr ok i looked nothings moved... they go from sas expander card to cable that splits to 4 satas into backplane... everything looks tight and nothing moves in there and a power on or device reset what does that mean that the hard drive turned off and turned back on... or it reset something?
June 6, 20233 yr ive seen this a few times i get that sweetalart but i get this when i downloading from the apps page a new app why is the preclear linked to downloading a new app? is it something i need to fix? tardis-diagnostics-20230606-1847.zip
June 7, 20233 yr why did i get another pre clear error? i not even running it now just parity building its its going extremly slow i dont know why but i get this error Jun 7 11:40:05 Tardis nginx: 2023/06/07 11:40:05 [error] 11505#11505: *753955 auth request unexpected status: 504 while sending to client, client: 192.168.0.227, server: , request: "POST /plugins/unassigned.devices.preclear/Preclear.php HTTP/1.1", host: "192.168.0.3", referrer: "http://192.168.0.3/Docker" tardis-diagnostics-20230607-1459.zip
June 7, 20233 yr ah well it says preclear Jun 7 11:40:05 Tardis nginx: 2023/06/07 11:40:05 [error] 11505#11505: *753955 auth request unexpected status: 504 while sending to client, client: 192.168.0.227, server: , request: "POST /plugins/unassigned.devices.preclear/Preclear.php HTTP/1.1", host: "192.168.0.3", referrer: "http://192.168.0.3/Docker" if its nginx why is iit posting preclear? is my question
