November 26, 20214 yr 1 hour ago, CryPt00n said: Logs are attached First of all it is still bound to VFIO as you can see from the Kernel driver in use: 01:00.0 System peripheral [0880]: Global Unichip Corp. Coral Edge TPU [1ac1:089a] Subsystem: Global Unichip Corp. Coral Edge TPU [1ac1:089a] Kernel driver in use: vfio-pci Kernel modules: apex That's mainly caused because you have a file named "vfio-pci - Kopie.cfg" in your /boot/config directory with this content: BIND=0000:01:00.0|10de:11c0 0000:01:00.1|10de:0e0b I would strongly recommend to remove both vifo files from the /boot/config directory and reboot. After that it should work just fine, if you changed the mapping in the template already like:
November 26, 20214 yr 30 minutes ago, ich777 said: First of all it is still bound to VFIO as you can see from the Kernel driver in use: 01:00.0 System peripheral [0880]: Global Unichip Corp. Coral Edge TPU [1ac1:089a] Subsystem: Global Unichip Corp. Coral Edge TPU [1ac1:089a] Kernel driver in use: vfio-pci Kernel modules: apex That's mainly caused because you have a file named "vfio-pci - Kopie.cfg" in your /boot/config directory with this content: BIND=0000:01:00.0|10de:11c0 0000:01:00.1|10de:0e0b I would strongly recommend to remove both vifo files from the /boot/config directory and reboot. After that it should work just fine, if you changed the mapping in the template already like: Have deleted both vfio and the vfio bak file now, tpu is still not showing up in the plugin. I have attached new logs. server-diagnostics-20211126-1944.zip
November 26, 20214 yr 1 hour ago, CryPt00n said: Have deleted both vfio and the vfio bak file now, tpu is still not showing up in the plugin. First your server enables the TPU after the plugin installation is finished: Nov 26 19:40:25 server kernel: apex 0000:01:00.0: enabling device (0000 -> 0002) A little while after that your server does this: Nov 26 19:41:00 server kernel: vfio-pci 0000:01:00.0: vfio_ecap_init: hiding ecap 0x1e@0x110 It seems like you've bound it to your NicehashOS too and that's why it's bound again to VFIO... -device vfio-pci,host=0000:01:00.0,id=hostdev0,bus=pci.4,addr=0x0 \ I think something is really miss configured that always binds the card to VFIO: 01:00.0 System peripheral [0880]: Global Unichip Corp. Coral Edge TPU [1ac1:089a] Subsystem: Global Unichip Corp. Coral Edge TPU [1ac1:089a] Kernel driver in use: vfio-pci Kernel modules: apex You can always check which modules are loaded from a unRAID terminal with the following command: lspci -k
November 26, 20214 yr Found it, the Nicehash VM was the problem. I removed the GPU from my Unraid system and the TPU then got assigned to the VM. Unassigned it, rebooted and now its working like expected. Thank you very much for your Help! Edited November 26, 20214 yr by CryPt00n
December 5, 20214 yr I setup Frigate with my Reolink 511, and it worked awesome out of the gate. But then, I felt saucy & moved to the 10-beta. Now, I can't get the UI to pull up from the Unraid Docker. No issue with the HA add-on...Not sure if it is my docker config or something I changed in either the BIOS (Asrock x570du - Changed default video from NVIDIA back to IPMI) or Unraid networking (toggled bridge mode off and back on). All other Unraid dockers have no issue, only Frigate. Same time, my previously working HA add-on Frigate Proxy went down with this error - 2021/12/04 23:26:11 [error] 352#352: *219 upstream prematurely closed connection while reading upstream, client: 172.30.X.Y, server: ccab4aaf-frigate-proxy, request: "GET / HTTP/1.1", upstream: "http://unraid-IP:5000/", host: "172.30.A.B:5000" I've deleted the docker folders & images, and tried multiple times again. I know it's working since it's constantly creating videos ~5MB videos. s6-init] making user provided files available at /var/run/s6/etc...exited 0. [s6-init] ensuring user provided files have correct perms...exited 0. [fix-attrs.d] applying ownership & permissions fixes... [fix-attrs.d] done. [cont-init.d] executing container initialization scripts... [cont-init.d] done. [services.d] starting services [services.d] done. [2021-12-04 23:14:24] frigate.app INFO : Starting Frigate (0.9.4-26ae608) Starting migrations [2021-12-04 23:14:24] peewee_migrate INFO : Starting migrations There is nothing to migrate [2021-12-04 23:14:24] peewee_migrate INFO : There is nothing to migrate [2021-12-04 23:14:24] frigate.mqtt INFO : MQTT connected [2021-12-04 23:14:24] detector.coral INFO : Starting detection process: 257 [2021-12-04 23:14:24] frigate.app INFO : Output process started: 259 [2021-12-04 23:14:24] ws4py INFO : Using epoll [2021-12-04 23:14:24] frigate.edgetpu INFO : Attempting to load TPU as usb [2021-12-04 23:14:24] frigate.app INFO : Camera processor started for driveway-right: 262 [2021-12-04 23:14:24] frigate.app INFO : Capture process started for driveway-right: 265 [2021-12-04 23:14:27] frigate.edgetpu INFO : TPU found [2021-12-04 23:14:24] ws4py INFO : Using epoll [2021-12-04 23:14:29] frigate.record WARNING : Discarding a corrupt recording segment: driveway-right-20211204231407.mp4 [2021-12-04 23:15:03] frigate.mqtt INFO : MQTT connected Edited December 5, 20214 yr by OneMeanRabbit
December 6, 20214 yr I'm not sure if this is the correct place for this question, so let me know if there is a better place to post. I've been using the Frigate docker container successfully on my Unraid server for many months with the Google Coral (USB Accelerator) and it has worked very well. A day or two ago I noticed that events weren't being registered in Frigate. I investigated, and it looks like my USB Coral is no longer setup correctly in Unraid. It looks like previously my Coral was passed through under /dev/bus/usb and /dev/dri/ (at least that is what was in the template for the container). Now I do not see anything under /dev/dri/. I did a little research and it looks like it might need to be under /dev/apex* but I do not have anything like that on my server. /bin/ls: cannot access '/dev/apex*': No such file or directory I uninstalled the plugin "Coral Accelerator Module Drivers", rebooted my server, installed the plugin again, rebooted, but I do not see any evidence that the plugin is recognizing my Coral. When I do lsusb, I see it: Bus 003 Device 003: ID 18d1:9302 Google Inc. In the Unraid GUI, if I go to Settings->Coral Driver, it only shows me the heading "Coral TPU Driver" but other than that, the page is completely blank with no statistics about by Coral. I've attached my Diagnostics file to this post. I would appreciate another set of eyes on this because I am having a hard time figuring this one out and my family is getting tired of all of my reboots Thanks in advance! storage-diagnostics-20211206-1527.zip
December 7, 20214 yr 2 hours ago, furiousgeorge said: I'm not sure if this is the correct place for this question, so let me know if there is a better place to post. I've been using the Frigate docker container successfully on my Unraid server for many months with the Google Coral (USB Accelerator) and it has worked very well. A day or two ago I noticed that events weren't being registered in Frigate. I investigated, and it looks like my USB Coral is no longer setup correctly in Unraid. It looks like previously my Coral was passed through under /dev/bus/usb and /dev/dri/ (at least that is what was in the template for the container). Now I do not see anything under /dev/dri/. I did a little research and it looks like it might need to be under /dev/apex* but I do not have anything like that on my server. /bin/ls: cannot access '/dev/apex*': No such file or directory I uninstalled the plugin "Coral Accelerator Module Drivers", rebooted my server, installed the plugin again, rebooted, but I do not see any evidence that the plugin is recognizing my Coral. When I do lsusb, I see it: Bus 003 Device 003: ID 18d1:9302 Google Inc. In the Unraid GUI, if I go to Settings->Coral Driver, it only shows me the heading "Coral TPU Driver" but other than that, the page is completely blank with no statistics about by Coral. I've attached my Diagnostics file to this post. I would appreciate another set of eyes on this because I am having a hard time figuring this one out and my family is getting tired of all of my reboots Thanks in advance! storage-diagnostics-20211206-1527.zip 153.16 kB · 0 downloads Same thing happened to me, I solved it by changing the docker UI from "/dev/bus/usb" to "/dev/bus/usb/003/003" in your case. Hope this helps, mine finds it and records - just lost all UI around the same time...
December 7, 20214 yr 15 hours ago, OneMeanRabbit said: Same thing happened to me, I solved it by changing the docker UI from "/dev/bus/usb" to "/dev/bus/usb/003/003" in your case. Hope this helps, mine finds it and records - just lost all UI around the same time... Wow - that fixed it! Thank you so much for the help!
December 7, 20214 yr Author On 12/5/2021 at 6:28 AM, OneMeanRabbit said: I setup Frigate with my Reolink 511, and it worked awesome out of the gate. But then, I felt saucy & moved to the 10-beta. Now, I can't get the UI to pull up from the Unraid Docker. No issue with the HA add-on...Not sure if it is my docker config or something I changed in either the BIOS (Asrock x570du - Changed default video from NVIDIA back to IPMI) or Unraid networking (toggled bridge mode off and back on). All other Unraid dockers have no issue, only Frigate. Same time, my previously working HA add-on Frigate Proxy went down with this error - 2021/12/04 23:26:11 [error] 352#352: *219 upstream prematurely closed connection while reading upstream, client: 172.30.X.Y, server: ccab4aaf-frigate-proxy, request: "GET / HTTP/1.1", upstream: "http://unraid-IP:5000/", host: "172.30.A.B:5000" I've deleted the docker folders & images, and tried multiple times again. I know it's working since it's constantly creating videos ~5MB videos. s6-init] making user provided files available at /var/run/s6/etc...exited 0. [s6-init] ensuring user provided files have correct perms...exited 0. [fix-attrs.d] applying ownership & permissions fixes... [fix-attrs.d] done. [cont-init.d] executing container initialization scripts... [cont-init.d] done. [services.d] starting services [services.d] done. [2021-12-04 23:14:24] frigate.app INFO : Starting Frigate (0.9.4-26ae608) Starting migrations [2021-12-04 23:14:24] peewee_migrate INFO : Starting migrations There is nothing to migrate [2021-12-04 23:14:24] peewee_migrate INFO : There is nothing to migrate [2021-12-04 23:14:24] frigate.mqtt INFO : MQTT connected [2021-12-04 23:14:24] detector.coral INFO : Starting detection process: 257 [2021-12-04 23:14:24] frigate.app INFO : Output process started: 259 [2021-12-04 23:14:24] ws4py INFO : Using epoll [2021-12-04 23:14:24] frigate.edgetpu INFO : Attempting to load TPU as usb [2021-12-04 23:14:24] frigate.app INFO : Camera processor started for driveway-right: 262 [2021-12-04 23:14:24] frigate.app INFO : Capture process started for driveway-right: 265 [2021-12-04 23:14:27] frigate.edgetpu INFO : TPU found [2021-12-04 23:14:24] ws4py INFO : Using epoll [2021-12-04 23:14:29] frigate.record WARNING : Discarding a corrupt recording segment: driveway-right-20211204231407.mp4 [2021-12-04 23:15:03] frigate.mqtt INFO : MQTT connected If beta is not working go back to stable. Anyway, this looks something regarding to your configuration or docker deployment. I'm running 10 beta 4 for past 2 weeks with no issues at all.
December 7, 20214 yr Author 21 hours ago, furiousgeorge said: I'm not sure if this is the correct place for this question, so let me know if there is a better place to post. I've been using the Frigate docker container successfully on my Unraid server for many months with the Google Coral (USB Accelerator) and it has worked very well. A day or two ago I noticed that events weren't being registered in Frigate. I investigated, and it looks like my USB Coral is no longer setup correctly in Unraid. It looks like previously my Coral was passed through under /dev/bus/usb and /dev/dri/ (at least that is what was in the template for the container). Now I do not see anything under /dev/dri/. I did a little research and it looks like it might need to be under /dev/apex* but I do not have anything like that on my server. /bin/ls: cannot access '/dev/apex*': No such file or directory I uninstalled the plugin "Coral Accelerator Module Drivers", rebooted my server, installed the plugin again, rebooted, but I do not see any evidence that the plugin is recognizing my Coral. When I do lsusb, I see it: Bus 003 Device 003: ID 18d1:9302 Google Inc. In the Unraid GUI, if I go to Settings->Coral Driver, it only shows me the heading "Coral TPU Driver" but other than that, the page is completely blank with no statistics about by Coral. I've attached my Diagnostics file to this post. I would appreciate another set of eyes on this because I am having a hard time figuring this one out and my family is getting tired of all of my reboots Thanks in advance! storage-diagnostics-20211206-1527.zip 153.16 kB · 0 downloads For USB coral you don't need the Driver pluging, that only works for PCI and M.2 coral cards. It looks you have changed the config file of your frigate. Make sure you have these: detectors: coral: type: edgetpu device: usb And not these: detectors: coral: type: edgetpu device: pci The USB tpu mapping is /dev/bus/usb. /dev/dri/ is mapped for hardware acc. of intel CPUs.
December 7, 20214 yr Author 2 hours ago, furiousgeorge said: Wow - that fixed it! Thank you so much for the help! 18 hours ago, OneMeanRabbit said: Same thing happened to me, I solved it by changing the docker UI from "/dev/bus/usb" to "/dev/bus/usb/003/003" in your case. Hope this helps, mine finds it and records - just lost all UI around the same time... Be aware that pointing to an specific usb port will not work if you reboot your Unraid machine as port may change to another number. Thast why the mapping is done to the entire USB driver to let frigate find it whatever the port number is. Edited December 7, 20214 yr by yayitazale
December 8, 20214 yr 8 hours ago, furiousgeorge said: Wow - that fixed it! Thank you so much for the help! Glad it worked, and as @yayitazale said, it will change at boot. When mine rebooted, I went back to the default /dev/bus/usb with no issue since.
December 8, 20214 yr Now that Frigate is running in the dockers satisfactory at the moment . How can you install the Frigate integration addon to use the cameras motion ,detection options to turn on switches/devices mainly on one of my cameras? Hacs is install on VM for HA. Any help would be appreciated.
December 9, 20214 yr 18 hours ago, mikey6283 said: Now that Frigate is running in the dockers satisfactory at the moment . How can you install the Frigate integration addon to use the cameras motion ,detection options to turn on switches/devices mainly on one of my cameras? Hacs is install on VM for HA. Any help would be appreciated. Google is your friend, here's a walk-through, github with docs straight from the man, & Home Assistant's community for further help with Frigate integration/Frigate Proxy/HACS. https://smarthomepursuits.com/how-to-install-frigate-in-home-assistant-for-pt1/ https://github.com/blakeblackshear/frigate-hass-addons https://community.home-assistant.io/c/third-party/15
December 15, 20214 yr Brand new user - would like to try this docker out for my CCTV/NVR needs. I am unable to try to see/edit/verify the /config/config.yml file as the whole docker stops and so getting to terminal won't work because the session closes. How do I troubleshoot this? Basic install of the Nvidia version of the docker. Only thing I edited was changing media path to an unassigned disk out of the array, added the GPU ID for Nvidia card and password. When I run it it auto-closes with logs showing: ----------- [s6-init] making user provided files available at /var/run/s6/etc...exited 0. [s6-init] ensuring user provided files have correct perms...exited 0. [fix-attrs.d] applying ownership & permissions fixes... [fix-attrs.d] done. [cont-init.d] executing container initialization scripts... [cont-init.d] done. [services.d] starting services [services.d] done. ************************************************************* ************************************************************* *** Your config file is not valid! *** *** Please check the docs at *** *** https://docs.frigate.video/configuration/index *** ************************************************************* ************************************************************* *** Config Validation Errors *** ************************************************************* [Errno 2] No such file or directory: '/config/config.yml' ************************************************************* *** End Config Validation Errors *** ************************************************************* [cmd] python3 exited 1 [cont-finish.d] executing container finish scripts... [cont-finish.d] done. [s6-finish] waiting for services. [s6-finish] sending all processes the TERM signal. [s6-finish] sending all processes the KILL signal and exiting.
December 15, 20214 yr Author 2 minutes ago, Ystebad said: Brand new user - would like to try this docker out for my CCTV/NVR needs. I am unable to try to see/edit/verify the /config/config.yml file as the whole docker stops and so getting to terminal won't work because the session closes. How do I troubleshoot this? Basic install of the Nvidia version of the docker. Only thing I edited was changing media path to an unassigned disk out of the array, added the GPU ID for Nvidia card and password. When I run it it auto-closes with logs showing: ----------- [s6-init] making user provided files available at /var/run/s6/etc...exited 0. [s6-init] ensuring user provided files have correct perms...exited 0. [fix-attrs.d] applying ownership & permissions fixes... [fix-attrs.d] done. [cont-init.d] executing container initialization scripts... [cont-init.d] done. [services.d] starting services [services.d] done. ************************************************************* ************************************************************* *** Your config file is not valid! *** *** Please check the docs at *** *** https://docs.frigate.video/configuration/index *** ************************************************************* ************************************************************* *** Config Validation Errors *** ************************************************************* [Errno 2] No such file or directory: '/config/config.yml' ************************************************************* *** End Config Validation Errors *** ************************************************************* [cmd] python3 exited 1 [cont-finish.d] executing container finish scripts... [cont-finish.d] done. [s6-finish] waiting for services. [s6-finish] sending all processes the TERM signal. [s6-finish] sending all processes the KILL signal and exiting. You have to create and place a config file, the APP does not create one. Follow the manual/docs from here: https://docs.frigate.video/
December 29, 20214 yr I’ve got a couple of Reolink 410 cameras on order. Once they arrive I’ll be installing and setting up the Frigate-Nvidia docker for use with my Home Assistant vm. It’s mostly temporary since I’ve also got a Home Assistant Yellow (formerly Amber) on order and will be migrating over to it once they start shipping. Will probably also get the Coral USB dongle then. I’m curious if it’s possible to migrate the Frigate configuration to another machine or are the settings different enough that it’s better to just generate a new yml file? Edited December 29, 20214 yr by wgstarks Typo
December 29, 20214 yr Author 52 minutes ago, wgstarks said: I’ve got a couple of Reolink 410 cameras on order. Once they arrive I’ll be installing and setting up the Frigate-Nvidia docker for use with my Home Assistant vm. It’s mostly temporary since I’ve also got a Home Assistant Yellow (formerly Amber) on order and will be migrating over to it once they start shipping. Will probably also get the Coral USB dongle then. I’m curious if it’s possible to migrate the Frigate configuration to another machine or are the settings different enough that it’s better to just generate a new yml file? You will only need to change the ffmpeg parameters according to the documentation (and also the detectors parameters if you change the coral type) as this runs in a docker container.
December 29, 20214 yr 19 minutes ago, yayitazale said: You will only need to change the ffmpeg parameters according to the documentation (and also the detectors parameters if you change the coral type) as this runs in a docker container. That’s great. Will save a bunch of copy/pasting. Hopefully by the time I get my Yellow I’ll know what I’m doing with the config file.😁
December 30, 20214 yr Hi, I am working with the frigate docker container trying to use my amd apu for ffmpeg hardware acceleration. The docker container prefills the expected location of the gpu as `/dev/dri/renderD128` but `/dev/dri` does not exist. I do see a `/dev/vfio` but I am not sure if that is correct? Any help is greatly appreciated. Thanks! Quick note: Not currently using the igpu for anything else
January 1, 20224 yr Author On 12/30/2021 at 8:24 PM, crzynik said: Hi, I am working with the frigate docker container trying to use my amd apu for ffmpeg hardware acceleration. The docker container prefills the expected location of the gpu as `/dev/dri/renderD128` but `/dev/dri` does not exist. I do see a `/dev/vfio` but I am not sure if that is correct? Any help is greatly appreciated. Thanks! Quick note: Not currently using the igpu for anything else Is this supported? https://docs.frigate.video/configuration/hardware_acceleration
January 5, 20224 yr On 1/1/2022 at 9:38 AM, yayitazale said: Is this supported? https://docs.frigate.video/configuration/hardware_acceleration Yep, I had to whitelist amd drivers inside of unraid, after that it is working and hardware accelerating quite well.
January 5, 20224 yr Hi @yayitazale, I have 2 Coral TPU USB installed in UNRAID. Do I need to install the Coral Drivers in UNRAID or that is just for PCI/M.2 TPUs? Also, how do I passthrough the USB TPUs to the Frigate Docker in UNRAID? Thanks for your help!
January 6, 20224 yr I'm having a weird issue with this docker where if the docker is started, I can't start up my Windows VM. I'm not sure what the issue is. I'm using the nvidia docker passing in my Quadro and my Coral USB device. My Windows VM is using a GTX 1070 with its own PCIe USB card passed in. Home Assistant is being ran on an actual RPi 4. What could be causing this issue?
January 9, 20224 yr Author On 1/5/2022 at 4:59 AM, crzynik said: Yep, I had to whitelist amd drivers inside of unraid, after that it is working and hardware accelerating quite well. Maybe you need to add and enviromental argument: LIBVA_DRIVER_NAME=radeonsi https://docs.frigate.video/configuration/hardware_acceleration#amdati-gpus-radeon-hd-2000-and-newer-gpus-via-libva-mesa-driver
