Unassigned Devices - Managing Disk Drives and Remote Shares Outside of The Unraid Array

dlandon

By dlandon
in Plugin Support

Recommended Posts

Recommended

Posted by dlandon,

If you are seeing unexplained disk or remote share activity, it may be due to cache dirs caching all folders.  For those of you using the Cache Dirs plugin, you need to specify folders to be included so UD mounted disks and shares do not get included automatically.  This can also apply to pool disks.  It's really the best practice to specify the included folders so you control what is actually being cached.
Recommended by Squid

0 reactions

Go to this post
Recommended

Posted by dlandon,

New release of UD.  The changes are: - Add ability to spin down a disk by sdX.  You don't have to spin down disks by name= any more.  This is still available for spinning down a disk from a User Script because you won't know the correct sdX as it changes on reboot. - Add the ability to detach a disk when a UD script is finished using 'rc.unassigned'.  This detaches the disk from Unraid and should provide a potentially safer way to remove a USB device.  Applies to USB disks only. -
Recommended by SpencerJ
  • Upvote
  • Like

2 reactions

Go to this post
Recommended

Posted by dlandon,

There is a new feature in UD to help with plugins that need a mount point folder.  UD now creates a mount folder '/mnt/addons'.  This folder should be used to mount your plugin devices to prevent FCP warnings and keep your mounts separated from UD.  It is recommended you switch to this new folder for your addon and custom mounts.  You are welcome to leave the mounts at '/mnt/disks' or '/mnt/remotes'.  Things will still work, but if you request support for UD issues, you will be asked to remove t

UD is now creating a mount point folder for plugins and addons

Recommended by dlandon

0 reactions

Go to this post
Recommended

Posted by dlandon,

The recent changes to the way UD checks for remote servers being online were done to eliminate the inappropriate way UD was managing remote server names trying to get around local DNS name lookup issues.  The way it works now is using several methods to lookup server names after an IP address is found to have an open SMB or NFS port when searching for servers.  Nmblookup and avahi are used to find the names.  The issue comes when UD tries to verify the server is online with the servername and no
Recommended by dlandon

0 reactions

Go to this post
Phredwerd Noob

Phredwerd

Posted
Posted

It doesn't matter which USB port I plug either drive into, they both present with the same device ID. Even if I change the mount point this won't work.



So drive one's mount point is Video and the other drive is Space. If I plug in the first drive, it will mount as Video but if I then plug in the second drive whilst the first is also plugged in, Video disappears and Space takes it's place.



They are vastly different drives too! One is a 500GB Toshiba I lifted out of on an old mac book and the other a 1GB Hitachi. It's really bizarre.

Link to comment
  • Replies 10.8k
  • Created
  • Last Reply

Top Posters In This Topic

Popular Days

Top Posters In This Topic

Popular Days

Popular Posts

dlandon
dlandon

It's that self healing feature I built into UD.  It just fixes itself.

dlandon
dlandon

New release of UD.  Changes: When changing the mount point (which is also the share name), the mount point is checked for a duplicate of a user share or another UD device.  Samba cannot handle

dlandon
dlandon

Major new release of UD: "Where are the switches?"  The "Pass Through", "Read Only", "Automount", and "Share" switches have been moved to a new Edit Settings dialog.  This is also where the sc

Posted Images

dlandon Veteran

dlandon

Posted
  • Author
Posted
21 minutes ago, Phredwerd said:

It doesn't matter which USB port I plug either drive into, they both present with the same device ID. Even if I change the mount point this won't work.



So drive one's mount point is Video and the other drive is Space. If I plug in the first drive, it will mount as Video but if I then plug in the second drive whilst the first is also plugged in, Video disappears and Space takes it's place.



They are vastly different drives too! One is a 500GB Toshiba I lifted out of on an old mac book and the other a 1GB Hitachi. It's really bizarre.

Post diagnostics.

Link to comment
Kilrah Rising Star

Kilrah

Posted
Posted
14 hours ago, Phredwerd said:

They are vastly different drives too! One is a 500GB Toshiba I lifted out of on an old mac book and the other a 1GB Hitachi. It's really bizarre.

Just means it's the USB adapter you're using that doesn't pass the drive's ID as it should but its own. What interface is it? I have one of those dual docks that will also pass its own ID, and the same for both drives.

Link to comment
Phredwerd Noob

Phredwerd

Posted
Posted
7 hours ago, Kilrah said:

Just means it's the USB adapter you're using that doesn't pass the drive's ID as it should but its own. What interface is it? I have one of those dual docks that will also pass its own ID, and the same for both drives.



Yeeahh I was thinking this may have been the culprit. Both drives involved in this issue are encased in an Orico brand hard drive enclosure.



This one in particular:

https://www.orico.com.cn/product/detail/397.html



Link to comment
dlandon Veteran

dlandon

Posted
  • Author
Posted
6 hours ago, unr41dus3r said:



Hi,

i wanted to ask about an ETA for the new release? It would be really nice if i dont need to use the command every time per CLI.

Thanks

I am working on some zfs issues for 6.13 and want to finish those up first.  The latest release of zfs has caused me to have to make some changes.

  • Like 1
Link to comment
Phredwerd Noob

Phredwerd

Posted
Posted
On 11/5/2023 at 3:37 AM, Kilrah said:

Just means it's the USB adapter you're using that doesn't pass the drive's ID as it should but its own. What interface is it? I have one of those dual docks that will also pass its own ID, and the same for both drives.

Is there anyway to change how the USB adaptor in this device presents the ID? That's really annoying that it does that.

Link to comment
dlandon Veteran

dlandon

Posted
  • Author
Posted
4 hours ago, christophesimon said:

Here it is

Click on the double arrow icon in the upper right of the UD page and see if the disks show.  This will refresh udev.



I don't see the issue with the remote shares mount points.



I may have more ideas after I look at the diagnostics further.



Edit: Your Kingston cache disk is not being seen by Linux.  The only disks Unraid is seeing are your array disks.  Reboot your server and verify the disk is seen in the BIOS.

Link to comment
dlandon Veteran

dlandon

Posted
  • Author
Posted
10 minutes ago, comet424 said:

what does it mean with this   non mount  i get this on my sisters  unraid box and i seeen she getting some messed up warnings i not sure whats going on with her box

and with the UD

That means the file system type being reported by udev is not what is reported by Linux.  The disk is being reported by udev as a 'ntfs' formatted disk that is correct because the disk is mounted as a 'ntfs' disk.  Click on the double arrows icon at the upper right of the UD page and see if it doesn't fix it.



You also have a lot of out of memory issues being logged:

Nov  8 13:32:29 mitchsserver nginx: 2023/11/08 13:32:29 [crit] 23367#23367: ngx_slab_alloc() failed: no memory
Nov  8 13:32:29 mitchsserver nginx: 2023/11/08 13:32:29 [error] 23367#23367: shpool alloc failed
Nov  8 13:32:29 mitchsserver nginx: 2023/11/08 13:32:29 [error] 23367#23367: nchan: Out of shared memory while allocating message of size 14428. Increase nchan_max_reserved_memory.
Nov  8 13:32:29 mitchsserver nginx: 2023/11/08 13:32:29 [error] 23367#23367: *1358607 nchan: error publishing message (HTTP status code 500), client: unix:, server: , request: "POST /pub/disks?buffer_length=1 HTTP/1.1", host: "localhost"
Nov  8 13:32:29 mitchsserver nginx: 2023/11/08 13:32:29 [error] 23367#23367: MEMSTORE:01: can't create shared message for channel /disks


If you leave an Unraid session open on a computer, close it down.

Link to comment
comet424 Community Regular

comet424

Posted
Posted

ill have to do it next time my sister does it...  i rebooted her system and she pulled out her ssd...      ya i leave her Unraid open on my Desktop  so i have on my desktop i have a window  of my unraid  her unraid my backup unraid always running... is  that causing hers running out of memory?  is that what it said?



Link to comment
dlandon Veteran

dlandon

Posted
  • Author
Posted
16 minutes ago, comet424 said:

ill have to do it next time my sister does it...  i rebooted her system and she pulled out her ssd...      ya i leave her Unraid open on my Desktop  so i have on my desktop i have a window  of my unraid  her unraid my backup unraid always running... is  that causing hers running out of memory?  is that what it said?



Yes.  The nchan messaging process that triggers a UI refresh is stacking up messages because the consumer process has stopped responding and eventually runs out of memory for more messages.  This happens when the GUI is left open but stops responding to the nchan message requests.  For now it's best to only open the GUI when needed and then close it when it's no longer needed.

Link to comment
christophesimon Noob

christophesimon

Posted
Posted
17 hours ago, dlandon said:

Is it shown in the disk devices in the BIOS?  You'll have to find out why Linux is not seeing the disk.



Oh that's way out of my league ;-) I don't know how to do this therefore I think my cache SSD is now gone for good. Too bad since I thought that Unraid was a stable OS and now I am facing a massive fail.  It all just started from a plex update that escaladated.

Link to comment
dlandon Veteran

dlandon

Posted
  • Author
Posted
2 hours ago, christophesimon said:



Oh that's way out of my league ;-) I don't know how to do this therefore I think my cache SSD is now gone for good. Too bad since I thought that Unraid was a stable OS and now I am facing a massive fail.  It all just started from a plex update that escaladated.

The BIOS is what starts your server.  You enter the BIOS to adjust settings for the server as it starts up, but you can also see disk devices recognized by the BIOS.



If that is not something you want to do, power down your server, check cables and make sure one hasn't come loose.  If you don't find a problem there, then you're probably looking at a failed disk.



As @Kilrah said, Unraid has nothing to do with a drive not being recognized by Linux - i.e. a hardwre failures.

Link to comment
sittingmongoose Contributor

sittingmongoose

Posted
Posted

Is there a CLI for using unassigned devices?  Or CLI commands to mount shares in Unraid?  I tried the normal Linux methods to mount and had no success.



Some background, im using NFS to mount another remote(local) unraid share and it works, but after a few hours the share disconnects.  Unassigned devices thinks its still mounted but its not.  So I need to manually go in and click unmount and then mount again.  I was hoping to automate this with a script.

Link to comment
dlandon Veteran

dlandon

Posted
  • Author
Posted
1 minute ago, sittingmongoose said:

Is there a CLI for using unassigned devices?  Or CLI commands to mount shares in Unraid?  I tried the normal Linux methods to mount and had no success.



Some background, im using NFS to mount another remote(local) unraid share and it works, but after a few hours the share disconnects.  Unassigned devices thinks its still mounted but its not.  So I need to manually go in and click unmount and then mount again.  I was hoping to automate this with a script.

The issue is most likely a networking problem.  You should really work on solving any network issues.  That being said, yes there is a CLI for mounting and unmounting UD devices.  Click on the Help icon in the upper right hand corner of the GUI and you will see how to use the CLI.



The problem you will have is unmounting and re-mounting the remote share if files are being read or written when your script hammers the share by unmounting it at the wrong time.



I don't know your use case, but maybe you can set up a User Script to run on a cron to mount the remote share, do the work, and then un-mount the remote share.

Link to comment
